JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck

Categories Heavy Duty Dump Truck
Brand Name: JAC
Certification: CCC,ISO
Place of Origin: China
MOQ: 1unit
Price: USD38,500.00-USD40,000.00 per unit
Payment Terms: 30%TT as deposit, the balance should be paid before delivery; 100% irrevocable confirmed L/C at sight
Supply Ability: 3000units/month
Delivery Time: 30-45 days
Packaging Details: Nude packing after painted wax
Loading capacity: 20-30 tons
Drive wheel: 6x4
Engine capacity: > 8L
Fuel type: Diesel
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck

JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck


1,high-duty steel:main beam,side beam and key parts use domestic advanced technology standardlow-alloy and high-strengthsteel.
2,low consumption:light weight cut down fuel use and save transportation cost.
3,high return:reduce self-weight,increace customer's transportation profit.
Products Technical Specification
TypeJAC 6*4 Dump Truck
CabHalf row,single sleeper,with A/C
Vehicle Description
Overall dimensions(mm)7835*2495*3500
G.V.W (kg)25000
Curb weight(vehicle) (kg)11800
Loading capacity (kg)20000-30000
Max speed (Km/h)80
Engine
Engine modleWP10.300E40
Maximum power221kw (300hp)
Displacement (lit)9.726
Engine ManufacturerWeichai power Co., Ltd.
Chassis Description
Chassis modelHFC3241
Wheel base3490+1350
F/R track base(mm)2057/1880
F/R overhang(mm)1495/1500
Approach/Departure angle(°)27/26
Spring plate10/12
Front axle / rear axleSteyr
Type of fuelDiesel
Fuel of capacity350 L
Gear boxFAST , 10-speed with over drive
Electric system24V
Tyres11.00R20
Dumper body Description
Van dimensions(mm)5200*2300*1500 /1800
Van descriptionEquipped with material of carbon steel,
side 6mm thickness; bottom 8mm thickness
with middle / front lifting system
Optional EquipmentTires,Dumper body thickness,middle hydraulic ram,
side door,etc
