40Khz Emulsification Ultrasonic Extraction Equipment Titanium Horn

40Khz High Frequency Ultrasonic emulsification extraction equipment

Parameter

Description

Phacoemulsification refers to the process of mixing two (or more than two) immiscible liquids uniformly to form a dispersion system under the action of ultrasonic energy, and one of the liquids is evenly distributed in the other liquid to form an emulsion.

The physical mechanism of crushing insoluble solids (or liquids) is considered to be ultrasonic cavitation. Ultrasonic cavitation effect means that a large number of bubbles will be generated in the liquid under the action of strong ultrasonic waves. Small bubbles will gradually grow and increase with the ultrasonic vibration, and then suddenly burst and split, and the split bubbles will continue to grow and burst. . When these small bubbles collapse rapidly, high temperature and high pressure are generated in the bubble, and because the liquid around the bubble rushes into the bubble at high speed, a strong local shock wave is generated in the liquid near the bubble, and a local high temperature and high pressure is also formed. Ultrasonic pulverization and emulsification.

Industrial applications

In the pharmaceutical industry and the daily necessities industry, phacoemulsification is often used in the manufacture of various emulsion products, such as emulsion drugs, cosmetics, and shoe polish. Ultrasonic emulsification method can also be used to make emulsified combustion products of oil (gasoline, diesel, etc.) and water or pulverized coal to increase the combustion value per unit of fuel.
This technology has now been promoted and used in a limited range, and the economic benefits are obvious. In order to reduce costs and adapt to larger-scale production, mechanical ultrasonic transducers such as reed whistles are mostly used in phacoemulsification. For liquids that are difficult to emulsify or due to other special considerations, piezoelectric ultrasonic transducers are sometimes used, and an appropriate sound focusing system is used to increase the sound intensity.

Features

The average droplet size of the emulsion formed by ultrasonic emulsification is small, which can be 0.2 ~ 2um; the droplet size distribution range is narrow, which can be 01 ~ 10um or narrower.
The concentration of ultrasonic emulsion is high, the concentration of pure emulsion can exceed 30%, and the addition of emulsifier can be as high as 70%.
The formed emulsion is more stable. An important feature of phacoemulsification is that it can produce a very stable emulsion without or using less emulsifiers.
The type of emulsion can be controlled. Using phacoemulsification, under certain sound field conditions, both O/W (oil-in-water) and W/O (water-in-oil) emulsions can be prepared; however, it is impossible to use mechanical emulsification methods, only the properties of emulsifiers In order to control the type of emulsion.
Toluene is emulsified in water, one type of emulsion can be formed under low sound intensity conditions, and another type of emulsion can be formed under high sound intensity conditions.
Ultrasonic emulsification requires low power to produce milk residue.

R-Responsibility P-Products S-Service

sale the right products instead of the expensive one

Rps-sonic, consisted with a couple of young people who love ultrasonic very much.The founding members of RPS-SONIC have an average degree of Bachelor's degree or above. They have been in the ultrasonic industry for more than 5 years and have rich experience in ultrasound. The company's business philosophy is: Do not blindly promote any product, find the right product for the customer. So before each order, we will confirm all the details, including application details, equipment conditions, equipment specific information.

And we have the Professional import and export company， HangZhou LanBen Trade Co., Ltd, can export to any country wordwide.

Before year 2012, we only sale second branson / dukane / rinco / herrman/telsonic welding equipment , during these twenty year develop, we find, more and more people have problem with the core part of ultrasonic welding equipment -generator and transducer, so we decided to start our business of transducer and generator of our own transducer and generator. Many of the end user meet the transducer problem, they don’t know why transducer broken, and changing the expensive transducer one by one. Actually, one branson /dukane /rinco transducer can use 10~30 year, even the cheapest transducer can use about 5 years. So there must some reasons if your transducer broken in one year. That’s why we want build Rps-sonic, we need to help more end user to know more about transducer , to use ultrasonic equipment better, to save cost when meet problem.

The same to generator, Unreasonable operation may shorter the use-life of ultrasonic generator. So we have to make technical inquiry before operate ultrasonic welding machine. The key point of ultrasonic machine is resonance, only keep every part in resonance can make the system in best work environment.

Till now , we still have a lot of Branson /dukane/ rinco/ herrman telsonic welding machine, so that we can confirm every transducer/generator we made can matching to the original machine.

Of course we can make the transducer/generator replace for Branson /dukane/ rinco/ herrman telsonic welding machine, we can also make transducer/generator for any application of your ultrasonic equipment. We supply OEM service for oversea customers, we already have OEM customer in USA and German.

If you have any problem in ultrasonic area, welcome contact Rps-sonic.
