99% Al2O3 Dense Aluminum Oxide Ceramics 3.6g/Cm3 Density

Categories	Alumina Ceramic Parts
Brand Name:	ZG
Model Number:	MS
Certification:	CE
Place of Origin:	CHINA
MOQ:	1 piece
Price:	Negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000 Pieces per month
Delivery Time:	5-8 working days
Packaging Details:	Strong wooden box for global shipping
Application:	Bearings Mechanical Seals Bearings Valve Plates Ball Valves Nozzles Pipeline Lining Thermocouple Protection Tube
Material:	Al2O3 Aluminum Oxide, 95%, 99%
Color:	White
Size:	Customized
Shape:	Round, balls, Irregular, tube, Customized
Density:	>=3.6g / cm3
Feature:	Wear Resistant Corrosion Resistant Thermal Shock Resistant High Strength Air Impermeability
Product name:	Manufacturer Supplier 95%-99.8% Aluminum Oxide Ceramic Al2O3 Crucibles, alumina furnace tube, Al2O3 grinding polishing packing ceramic balls, alibaba china wear-resisting alumina ceramics, Al2O3 aluminium oxide alumina ceramic

Contact Now

Add to Cart

Company Info.

HENAN ZG INDUSTRIAL PRODUCTS CO.,LTD

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

99% Al2O3 Dense Aluminum Oxide Ceramics 3.6g/Cm3 Density

The Most Well-known Oxide Ceramic Material

Alumina or aluminum oxide (Al2O3) in its various levels of purity is used more often than any other advanced ceramic material. CeramTec offers a wide range of material types with different property profiles that can be adjusted via a targeted matrix design.

Aluminium oxide Related Data

Main component			99%Al2O3	S-SiC	ZrO2	Si3N4
Main component			99%Al2O3	S-SiC	ZrO2	Si3N4
Physical Property	Density	g/cm3	3.9	3.1	6	3.2
	Water Absorption	%	0	0.1	0	0.1
	Sinter Temperature	°C	1700	2200	1500	1800
Mechanical Property	Rockwell Hardness	HV	1700	2200	1300	1400
	Bend Strength	kgf/mm2	3500	4000	9000	7000
	Compression Intensity	Kgf/mm2	30000	20000	20000	23000
Thermal Property	Maximum working temperature	°C	1500	1600	1300	1400
	thermal expansion coefficient 0-1000°C	/°C	8.0*10-6	4.1*10-6(0-500°C)	9.5*10-6	2.0*10-6(0-500°C)
	thermal expansion coefficient 0-1000°C	/°C	8.0*10-6	5.2*10-6(500-1000°C)	9.5*10-6	4.0*10-6(500-1000°C)
	Thermal Shock resistance	T(°C)	200	250	300	400-500
	Thermal Conductivity	W/m.k(25°C	31	100	3	25
	Thermal Conductivity	300°C)	16	100	3	25
Electrical Property	Resisting rate of Volume	◎.cm
	20°C		>1012	106-108	>1010	>1011
	100°C		1012-1013	–	–	>1011
	300°C		>1012	–	–	>1011
	Insulation Breakdown Intensity	KV/mm	18	semiconductor	9	17.7
	Dielectric Constant (1 MHz)	(E)	10	–	29	7
	Dielectric Dissipation	(tg o)	0.4*10-3	–	–	–

Aluminum oxide (Al2O3) has an exceptional set of properties:

high hardness;
good heat conductivity;
excellent corrosion resistance;
low density;
stability in a wide range of temperatures;
electrical insulation properties;
low cost relative to other ceramic materials.

All these combinations make the material irreplaceable in the manufacture of corrosion-resistant, wear-resistant, electrical insulating and heat-resistant products for a variety of industries.

There are two main types of aluminum oxide:

Dense Aluminum Oxide (Al2O3)
Refractory Alumina (Al2O3)

Dense Aluminum Oxide (Al2O3)
This material is used in production of responsible and mechanically loaded products, i.e. mainly as engineering and structural ceramics. The material has excellent corrosion-resistant, wear-resistant, electrical insulating and heat-resistant properties, in addition to resistance to thermal shock. If a thermal shock is present during operation, it is recommended to use refractory materials.

There are several modifications of dense aluminum oxide depending on the content of the main phase and admixtures, which differ in strength and chemical resistance (ALOX-AP, ALOX-HP).

Basic properties of the material

Properties	Brand of material
Properties	ALOX-AP	ALOX-HP
	Al2O3 94-96%	Al2O3 99,7%
Density, g/sm3	3,6-3,7	3,8-3,9
Isolated porosity, %	0	0
Hardness, GPa	12-13	15-17
Flexural strength, MPa	300-330	350-400
Compressive strength, MPa	2000-2200	2000-2400
Thermal conductivity at 20-100°С, W/mK	20-25	28-33
Coefficient of linear thermal expansion at 20-1000°С, 10-6К-1	7,0-8,0	7,0-8,0
Maximum operating temperature Oxidative environment A reducing or inert environment	1500 1500	1750 1750

The main applications are:

bearings for pumps and compressors;
rings of mechanical seals;
ceramic plungers;
elements of valves and stop valves;
lining for protection from wear and corrosion;
grinding bodies;
lining for cyclones and calciners for cement plants;
nozzles;
crucibles, boats;
covers and tubes of thermocouples, rods;
burners;
electro technical ceramics;
products for the glass industry;
furniture and lining of furnaces;
positional and welding pins for the automotive industry;
products for the paper and printing industry;
drags, eyes, dies, thread guides;
substrates, plates;
products for the metallurgical industry;
abrasive and building materials, tools, welding ceramics;
products for chemistry and petro chemistry.
