31QB-10141 R480-9 Hyundai Excavator Swing Reduction Gear

Categories Swing Reduction Gear
Brand Name: PNC
Model Number: Hyundai Excavator
Place of Origin: Made in china
MOQ: 1PC
Price: Negotiable
Payment Terms: T/T, Western Union, Paypal
Delivery Time: 2-3 working days
Packaging Details: Wooden box
Nc No.: NC-SG011
Model: R480LC9, R480LC9A, R480LC9S, R520LC9, R520LC9A, R520LC9S
Part No.: 31QB-10141, 31QB10141
Quality: Hyundai genuine
Stock: Lots of stock
Weight: 250-280 kgs
Warranty: 3 months
Product name: R480-9 Swing Reduction As., R520-9 Swing Reducer
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

31QB-10141 R480-9 Hyundai Excavator Swing Reduction Gear

31QB-10141 Swing Gearbox R480-9 Hyundai Excavator Swing Reduction Gear

Description

R480-9 Swing Reduction As., R520-9 Swing Reducer, Hyundai Reduction Assy

Application

Hyundai Excavator

Model

R480LC9, R480LC9A, R480LC9S, R520LC9, R520LC9A, R520LC9S

Part No.

31QB-10141, 31QB10141

Quality

OEM quality, Hyundai genuine

Weight

250-280kgs

Packing

heavy items pack into wooden case

MOQ

1PC

Lead time

About 1-3 working days

Payment

TT, Western union, Paypal, Paysend, RMB

Warranty

3 Months

Shipping Port

Huangpu Old Port, Shenzhen Yantian,Guangzhou


Compatible models:
9-SERIES CRAWLER EXCAVATOR R480C9MH R480LC9 R480LC9A R480LC9S R520LC9 R520LC9A R520LC9S Hyundai


Parts on group R480-9S swing reduction gear (type 1):

Pos.Part NoQtyParts nameComments
*-2.31QB-10140[1]SWING REDUCTION GEAR
*-2.31QB-10141[1]SWING REDUCTION GEAR
*-2.31QB-10141AR[1]SWING REDUCTION GEAR
1.XKAQ-00637[1]CASING
1.XKAQ-00964[1]CASING
2.XKAQ-00752[1]SHAFT-DRIVE
2.XKAQ-00645[1]SHAFT-DRIVE
3.XKAQ-00026[1]BEARING-ROLLER
4.XKAQ-00032[1]SEAL-OIL
5.XKAQ-00029[1]BEARING-ROLLER
5.XKAQ-00647[1]BEARING-ROLLER
5.XKAQ-00961[1]BEARING-ROLLER
6.XKAQ-00753[1]CARRIER ASSY 2
7.XKAQ-00075[1]CARRIER 2
8.XKAQ-00023[3]GEAR-PLANET 2
9.XKAQ-00643[3]PIN ASSY 2
10.XKAQ-00070[1]PIN 2INCL 11
N11.XKAQ-00291[1]BUSHING 2
12.XKAQ-00644[6]WASHER-THRUST
13.XKAQ-00048[6]PIN-SPRING
14.XKAQ-00754[1]CARRIER ASSY 1INCL 13
15.XKAQ-00531[1]CARRIER 1
16.XKAQ-00646[3]GEAR-PLANET 1
17.XKAQ-00415[3]PIN 1
18.XKAQ-00030[3]CAGE-NEEDLE
19.XKAQ-00417[3]PLATE 1-SIDE
20.XKAQ-00416[3]PLATE 2-SIDE
21.XKAQ-00041[3]RING-STOP
22.XKAQ-00755[1]GEAR-SUN 2
23.XKAQ-00648[1]GEAR-SUN 1
24.XKAQ-00534[1]PLATE-SIDE 3
25.XKAQ-00649[1]GEAR-RING
25.XKAQ-00779[1]GEAR-RING
26.XKAQ-00072[2]PIN-KNOCK
27.XKAQ-00404[1]PLATE-THRUST
28.XKAQ-00074[1]RING-STOP
29.XKAQ-00287[1]GEAR-PINIONOLD
29.XKAQ-00978[1]GEAR-PINIONNEW
30.XKAQ-00018[1]SPACER
31.XKAQ-00031[1]PLATE-COVER
32.XKAQ-00064[8]BOLT-HEX
33.XKAQ-00043[1]PLATE-LOCK
34.XKAQ-00042[2]BOLT-HEX
35.XKAQ-00044[1]WASHER-LOCK
36.XKAQ-00065[12]BOLT-SOCKET
37.XKAQ-00049[1]PLUG
38.XKAQ-00274[2]PLUG


Warranty Statement:

1. Warranty Type: We will replace the product which have quality problem.


2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

Contact with us and offer the data, photos of the problem items


3. You need to pay for the replacement charge for following condition:

* Wrong Order from customer.
* Natural Disasters cause the damage.
* Error installation, improper use.
* The machine and reducer work over time and over load.
* Lost by any condition.
* Human element destroyed.
* Corrode with rust during stock and running.
* Warranty Expired.


FAQ :

Q1: How can i make payment ?

A : Bank transfer, Western union, Paypal, Paysend, or RMB.
bank transfer take 2-3days, while we can arrange order once received the remittance copy.


Q2: How fast you can do shipment?

A: Stock items take 1-2days, no stock items 5-7 working days. It depends on the items and the quantity of your order. We will try best to ship goods on time,

won't let you and your client down.


Q3: If we dont find what we want on your website, what should we do?

A: talk with us directly on whatsapp, email, wechat, or phone, we will check inquirys asap. excavator parts have thousands kinds, it's not possible to post

all production online.


Q4. Do your product been tested before delivery?

A: Yes, all product been tested to make sure they are qualified to sell.


Q5: Can we buy 1 pc of each item for quality testing?
A: Yes, we value every customer, no matter order amount small or big, with grateful for your trust.
