| Categories | Outdoor LCD Digital Signage |
|---|---|
| Brand Name: | TOPADKIOSK/OEM |
| Model Number: | TPK-OW5565 |
| Certification: | CE&Rohs&FCC |
| Place of Origin: | CHINA |
| MOQ: | 1PC |
| Price: | negotiate |
| Payment Terms: | T/T, , MoneyGram |
| Supply Ability: | 3000pcs per month |
| Delivery Time: | 10-15days after receipt of your payment |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Pnale size: | 55 inch |
| Screen surface: | 6mm AR glass |
| Material: | Aluminum alloy,tempered glass |
| Temperature control: | rol: fan cooling/air conditioner |
| Connectivity: | LAN, WIFI, 3G(Optional) |
| System: | Window OS / Android |
| Anti-UV: | Yes,insulate 99.9% UV |
| Working Environement: | -40~+55 deg C,Humidity 50% |
| Seal: | double layer seal |
| Company Info. |
| Shenzhen TopAdkiosk Display Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
| LCD Panel Parameter | |
| Panel Size | 32-75 |
| Panel Brand | LG/Samsung/AUO/BOE etc |
| Installation | outdoor |
| Panel Type | HIGH nits LCD screen & patent LED backlight |
| Max Resolution (pixel) | 1920(RGB)*1080(FHD) |
| Aspect Ratio | 16:09 |
| Display Color | 16.7M(8bit) |
| light sensor | auto adjust brightness according to the surrounding enviroment |
| Brightness | 1500-2000cd/m2 |
| Contrast Ratio | 4000:1 |
| View Angle | 89°/89°89°/89°(Typical) |
| Response Time | 6ms(Typical) |
| Technical Specification | |
| Frame material | 1.5mm agalvanized sheet |
| Colored System | PAL/NTSC/Auto-detecting |
| Menu Language | Multiple language,English(Default) |
| Noise Reduction | Yes |
| Voltage Frequency | 100V-240V AC |
| Horizon Frequency | 50/60Hz |
| Working Temperature | 0°C~50°C |
| Working Humidity | 10% - 90% no condensation |
| Storage Temperature | -20°C - 80°C |
| Storage Humidity | 85% no condensation |
| Operating System | |
| Android | |
| Android CPU(Standard) | Dual Core Allwinner A201.5GHz |
| Optional CPU | Rockship RK3188 quad-core 1.6GHz |
| Memory | DDR3 1GB |
| Built-in Storage | 4GB FLASH for A20,8G for RK3188, Support TF card expansion |
| RJ45/WIFI/4G/USB/CF/SD | Include |
| Touch Funcion | Optional |
| Touch sensor | capacitive/infrared |
| Touch surface | 9H Anti-glare Tempered Glass |
| Windows | |
| CPU | Core 3217U, 3317U, 3517U; H81 i3, H81 i5. H81 i7 |
| Memory | RAM 4GB |
| Build-in storage | 500 HDD |
| RJ45/WIFI/4G/USB/TF/SD | Include |
| V59 | |
| CPU | No |
| Memory | SD/USB |
| WIFI/RJ45/3G/4G | No |
| HDMI output | No HDMI output |
| Infrared or capacitive touch | No |
| Support software installing application | Application is not supported |
| Temperature control system | |
| air Cooling | smart fan |
| cold and warm air conditioner | fixed frequency and variable frequency air conditioner |
| Optional function | |
| remote environment monitoring system | |
Configuration options:
| 1. Touch screen option | Nano, Capacitive |
| 2. Network version | LAN/WIFI/3G as options, remote control from server |
| 3. All in one PC | Integrated PC board, custom hardware. |
| 4. Standalone Ad function | With professional advertising playerboard. |
| 5. Monitor only | With DVI/VGA input, flexible connecting your device. |
Advantage
1. High brightness, high definition full HD lcd panel;
2. Anti-refiective glass with less than 3%low refiectivity;
3. Low humidity and constant temperature inner system enviroment
allows LCD panel to perform optimally;
4. With light sensor, automatically adjust the brightness,
environmental friendly and maximum energy saving.
1. Unique patented sealing technology;
2. Outdoor security anti-corrosion more than 8 years;
3. IP65 protection grade enclosure dust can not enter into the
display under the 20 mbar pression, harmless when water jetting in
ever direction.
1. Intelligent air conditioner cooling system integrated cooling
and heating;
2. Unique patented intelligent temperature control technology;
3. Work stably and efficiently in wide temperature range from -40°C
to +55°C;
4. housing enclosure made of non-oxidizing material zinc coted
steel.
|
