| Categories | Wire Braid Hydraulic Hose |
|---|---|
| Brand Name: | Yeli |
| Model Number: | HOG1B |
| Place of Origin: | China |
| MOQ: | 1000Meter |
| Price: | negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200,000 meter per month |
| Delivery Time: | 15-20 working days |
| Packaging Details: | wrapped with yellow/white woven belt or plastic firm |
| Reinforcement: | High Tensile Steel Wire,high-tensile steel wire.,2 layers of steel wire braid |
| Material: | Synthetic Rubber,Rubber+Steel wire |
| Size: | 1/4"~2" |
| Cover: | Weather Resistant Synthetic Rubber,oil-resistant synthetic(Nitrile).,One layer of oil and weather resistant synthetic rubber,Cloth |
| Application: | Industrial,suitable to carry hydraulic fluids,used for hydraulic oil delivery,high imPUlse hydraulic applications. |
| Length: | 20m-100m |
| Name: | 20m Length Sae 1sn / 2sn 2 Inch Braided Hydraulic Hose |
| Surface: | Black Wrapped,cloth/smooth surface hydraulic hose,Smooth or Wrapped |
| Working pressure: | 16.5 to 45Mpa |
| Working temperature: | -40℃ to +100℃ or -40℉ to +212℉ |
| Oem service: | Accept,Yes |
| keyword: | braided hydraulic hose |
Brand Name: Yeli, Thompson
Model Number: SAE 1SN/2SN/R1/R2
Processing Service: Moulding, Cutting
Material: synthetic rubber
Name: SAE 1SN/2SN/R1/R2 1/4" to 2" hydraulic rubber hose
Size: 3/16" - 2"
Tube: oil resistant synthetic rubber
Temperature range: -40℃~+100℃
Application: Industrial
Reinforcement: High Tensile Steel Wire Braided
Color: Black or colorful
Temperature: - 40C~+100C
Certification: ISO9001:2008
| DN | Hose I.D | Hose O.D | WorkingPressure | Burst Pressure | Minimum Bend Radius | Weight | Length | ||
| inch | mm | mm | MPa | MPa | mm | kg/m | meters | ||
| 5 | 3/16 | 4.8 | 11.5 | 25 | 100 | 90 | 0.201 | 20-100 | |
| 6 | 1/4 | 6.4 | 12.7 | 22.5 | 90 | 100 | 0.244 | 20-100 | |
| 8 | 5/16 | 7.9 | 14.4 | 21.5 | 86 | 115 | 0.274 | 20-100 | |
| 10 | 3/8 | 9.5 | 16..5 | 18 | 72 | 130 | 0.363 | 20-100 | |
| 13 | 1/2 | 12.7 | 19.5 | 16 | 64 | 180 | 0.447 | 20-100 | |
| 16 | 5/8 | 15.9 | 23 | 13.0 | 52 | 200 | 0.539 | 20-100 | |
| 19 | 3/4 | 19.1 | 26.7 | 10.5 | 42 | 240 | 0.690 | 20-100 | |
| 25 | 1 | 25.4 | 34.5 | 8.7 | 35 | 300 | 0.987 | 20-50 | |
| 32 | 1 1/4 | 31.8 | 42.2 | 6.3 | 25 | 420 | 1.205 | 20 | |
| 38 | 1 1/2 | 38.1 | 48.9 | 5.0 | 20 | 500 | 1.405 | 20 | |
| 51 | 2 | 50.8 | 61.9 | 4.0 | 16 | 630 | 1.910 | 20 | |
Our Services
1. Good Quality Braided Hydraulic Hose, We Will Ensure The Hose Working Pressure, Hardness And Good Raw Material.
2. We Are Rubber Braided Hydraulic Hose Factory With More Than 25 Years Rubber Braided Hydraulic Hose Production History, With Competitive Price, We Can Ensure We Will Suppy The Best Quality Braided Hydraulic Hose For You Within The Same Price In China Market.
3. Near Tianjin Port, Short Delivery Time, We Will Delivery The Braided Hydraulic Hoses For You With The Short Delivery Time.
4. We Will Supply The Best And Professional Exprot Serive For You. No Matter You Have Any Problem, Contact With Us Freely.

|
