| Categories | Spherical Roller Bearing |
|---|---|
| Brand Name: | SFT |
| Model Number: | 24032CA/CC/W33 |
| Place of Origin: | China |
| MOQ: | negotiable |
| Price: | negotiable |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000PCS/MONTH |
| Delivery Time: | 20-45DAYS |
| Packaging Details: | carton,pallet |
| Noise Level: | Z1,Z2,Z3,Z4 |
| Feature: | High Temperatuer Resistance |
| Reference Speed: | 1660 1/min |
| Weight: | 12.7KG |
| Number of Row: | Double row |
| Seals Type: | open |
High precision 160*240*80mm spherical roller bearings 24032CA/CC/W33 for machinery
Model: 20000CC, 20000CCK, 20000CC/W33, 20000CCK/W33, 20000CCK+H0000, 20000CCK/W33+H0000
Application: Precision instrument, Low noise motor, Automobile, motorcycle and other machines.
Description: Spherical roller bearing has two columns of roller, mainly endure radial load and also withstand any direction of axial load at the same time. This kind of bearing own a high capacity of radial load especially suitable for heavy load or vibration, but can’t bear pure axial load , The outer ring groove of this bearing is spherical, so it's favorable in regulating the heart. Spherical roller bearings and self-aligning ball bearing are the same at the structure theory and character, so they can substitute each other in the permission of load capacity and speed limit.
Spherical roller bearings have double-row rollers, one consumable ball, two surface rollers inside, and two outer ring surfaces that are oriented at an angle when rolling. Avoid the influence of the angle between the shaft and the bearing housing on the bearing or shaft bending, and it is suitable for installation and use or the situation where the shaft is bent and attracts the angle. To load.
Size and weight of spherical roller bearing:
| 24000 Series | ||
| ITEM | Mass (Kg) | D×d×B |
| 24032CAF3/W33 | 13 | 160×240×80 |
| 24032CAK30F3 | 13.2 | |
| 24032CAK30/C4W33 | 13.2 | |
| 24032CAK30/C3W33 | 13.2 | |
| 24032CA/C3S1W33 | 13.2 | |
| 24036CA | 26.6 | 180×280×100 |
| 24036CA/W33 | 26.6 | |
| 24036CAK30/W33 | 26.4 | |
| 24038CA | 22.9 | 190×290×100 |
| 24040CA | 31.3 | 200×310×109 |
| 24040CA/W33 | 31.3 | |
| 24040CAK30/W33 | 31.1 | |
| Bearing No. | Dimensions | Load ratings | Weight | |||||
| d | D | B | r | Dynamic | Static | |||
| Cylindrical bore | Tapered bore | mm | min | Cr (kN) | C0r (kN) | kg | ||
| 21304 CC | - | 20 | 52 | 15 | 1.1 | 30.8 | 31.2 | 0.18 |
| 21305 CC | - | 25 | 62 | 17 | 1.1 | 41 | 41 | 0.25 |
| 21306 CC | - | 30 | 72 | 19 | 1.1 | 55 | 60 | 0.38 |
| 21307 CC | - | 35 | 80 | 21 | 1.5 | 64 | 71 | 0.51 |
| 21308 CC | 21308 CCK | 40 | 90 | 23 | 1.5 | 80 | 96 | 0.71 |
| 21309 CC | 21309 CCK | 45 | 100 | 25 | 1.5 | 100 | 115 | 0.95 |
| 21310 CC | 21310 CCK | 50 | 110 | 27 | 2.0 | 115 | 132 | 1.00 |
| 21311 CC | 21311 CCK | 55 | 120 | 29 | 2.0 | 135 | 163 | 2.00 |
| 21312 CC | 21312 CCK | 60 | 130 | 31 | 2.1 | 161 | 210 | 1.95 |
| 21313 CC | 21313 CCK | 65 | 140 | 33 | 2.1 | 184 | 240 | 2.45 |
| 21314 CC | 21314 CCK | 70 | 150 | 35 | 2.1 | 207 | 260 | 3.00 |
| 21315 CC | 21315 CCK | 75 | 160 | 37 | 2.1 | 236 | 300 | 3.55 |
| 21316 CC | 21316 CCK | 80 | 170 | 39 | 2.1 | 255 | 335 | 4.20 |
| 21317 CC | 21317 CCK | 85 | 180 | 41 | 3.0 | 293 | 375 | 5.00 |
| 21318 CC | 21318 CCK | 90 | 190 | 43 | 3.0 | 322 | 425 | 5.80 |
| 21319 CC | 21319 CCK | 95 | 200 | 45 | 3.0 | 351 | 480 | 7.15 |
| 21320 CC | 21320 CCK | 100 | 215 | 47 | 3.0 | 385 | 530 | 8.80 |
| 21322 CC | 21322 CCK | 110 | 240 | 50 | 3.0 | 460 | 630 | 12.00 |
Drawing of spherical roller bearing:
spherical roller bearing features:
1. Accommodate misalignment
Spherical roller bearings are self-aligning like self-aligning ball bearings or CARB bearings.
2. High load carrying capacity
Spherical roller bearings are designed to accommodate both heavy radial loads and axial loads in both directions.
3. Long service life
The rollers are manufactured to such tight dimensional and geometrical tolerances that they are practically identical in a roller set. The symmetrical rollers self-adjust, providing optimal load distribution along the roller length and together with the special profile prevent stress peaks at the roller ends.
4. Low friction
Self-guiding rollers keep friction and frictional heat at low levels. A floating guide ring guides unloaded rollers so that they enter the load zone in the optimal position.
Robust
All spherical roller bearings contain strong window- or prong-type cages.
|
