STAINLESS STEEL FLANGE ASTM A182 / ASME SA182 F904L UNS N08904 SORF

ASTM A182 / ASME SA182 F904L (UNS N08904) Raised Face Slip On (SORF) Stainless Steel Flanges

Stainless Steel 904L Flange is a method of connecting pipes, valves, pumps and other equipment to form a piping system. It also provides easy access for cleaning, inspection or modification. Flanges are usually welded or screwed. Flanged joints are made by bolting together two flanges with a gasket between them to provide a seal.

Stainless Steel 904L Flange is a non-stabilized austenitic stainless steel with low carbon content. This high alloy stainless steel is added with copper to improve its resistance to strong reducing acids, such as sulphuric acid. The steel is also resistant to stress corrosion cracking and crevice corrosion. Grade 904L is non-magnetic, and offers excellent formability, toughness and weldability.

Stainless Steel 904L Flange contains high amounts of expensive ingredients, such as molybdenum and nickel. Today, most of the applications that employ grade 904L are replaced by low-cost duplex stainless steel 2205.

Stainless Steel Flange ASME SA182 F904L Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	EN	AFNOR	JIS	BS	KS
SS 904L	1.4539	N08904	X1NiCrMoCu25-20-5	Z2 NCDU 25-20	SUS 904L	904S13	STS 317J5L

Chemical Composition of Grade 904L Stainless Steel Flanges

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Cu
SS 904L	0.020 max	2.00 max	1.00 max	0.040 max	0.030 max	19.00 – 23.00	4.00 – 5.00 max	23.00 – 28.00	1.00 – 2.00

Mechanical Properties of ASTM A182 / SA 182 SS 904L Pipe Flanges

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.95 g/cm3	1350 °C (2460 °F)	Psi – 71000 , MPa – 490	Psi – 32000 , MPa – 220	35 %

ASTM A182 F904L Stainless Steel Flanges

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	ASTM A182, ASME SA182
ASME B16.5 904L SS Flange size range	1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000
ASTM A182 Stainless Steel 904L Flanges Standards	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges, ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN
Main Types	Forged / Threaded / Screwed / Plate
Types of Stainless Steel 904L Flanges	Blind Ring Flange (BLRF) Lap Joint Ring Flange (LJRF) Socket Weld Ring Flange (SWRF) Threaded Ring Flange Weld Neck Ring Flange (WNRF) Slip-On Ring Flange (SORF) Ring Type Joint Flange (RTJF)
904L Stainless Steel Flange Pressure Ratings	DIN:PN6 PN10 PN16 PN25 PN40; ANSI: class: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-PN6, PN10, PN16, PN25, PN40, PN64 etc. JIS: 5K, 10 K, 16 K 20 K,30 K,40 K, 63 K;
Production technique	Forged, Heat treated and machined
Connect Type/ Flange Face Type	Ring Type Joint (RTJ), Flat Face (FF), Lap-Joint Face (LJF), Raised Face (RF), Large Male-Female (LMF), Small Male-Female (SMF), Large Tongue & Groove, Small Tongue, Groove
Special design	As per your drawing AS, ANSI, BS, JIS and DIN 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations SS 904L Slip-On Flange, Threaded Flange, Weld Neck Flange, Blind Flange, Socketweld Flange
Test	Hydrostatic testing machine, Direct-reading Spectrograph, Magnetic particle detector, X-ray detector,UI trasonic flaw detector,Magnetic particle detector
Equipment	Pushing Machine,Bending machine, Press machine ,electric bevelling machine, Sand-blasting machine etc
Standard	ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. ANSI Flange, ASME Flange,BS Flange, EN Flange, API 6A Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/KS Flange, BS4504 Flange, GB Flange, GOST Flange, PSI Flange,AWWA C207 Flange B.S : BS4504 , BS3293, BS1560, BS10 DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638 ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48 ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 AS 2129: table D; table E; table H The other standard:AWWA C207;EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203;UNI2276 American standard (ANSI) German (DIN) British standard (BS) Any other specilised flanges
AMERICAN SOCIETY OF MECHANICAL ENGINEERS (ASME)	ASME B1.20.1, Pipe Threads, General Purpose ASME B16.1, Cast Iron Flanges and Flanged Fittings Classes 25, 125 and 250 ASME B16.5, Pipe Flanges and Flanged Fittings NPS 1/2 Through NPS 24 ASME B16.11, Forged Fittings, Socket Welding and Threaded ASME B16.25, Buttwelding Ends ASME B16.36, Orifice Flanges ASME B16.47, Large Diameter Steel Flanges NPS 26 Through NPS 60 ASME B31.1, Power Piping ASME B31.3, Process Piping ASME B46.1, Surface Texture (Surface Roughness, Waviness, and Lay)
Key markets and industries for ASTM A182 F904L Flanges	Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids.
Straight Piping Connection Application	To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc
904L Stainless Steel Pipe Flanges Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc

Applications

1. Oil and Gas Industry
2. Chemical Industry
3. Petrochemical Industry
4. Power Plant Industry
5. Refinery Industry
6. Food Processing Industry
7. Energy Industry
8. Aerospace Industry
9. Pulp & Paper Industry
