Stranded Loose Tube 2km GYTY53 Direct Burial Armored Cable

GYFTY53 Stranded Loose Tube Armored Cable

The fibers, 250µm, are positioned in a loose tube made of a high
modulus plastic. The tubes are filled with a water-resistant
filling compound. A steel wire locates in the center of core as a
strength member. The tubes (and fillers) are stranded around the
strength member into a compact and circular core. Then the cable
core is covered with a thin polyethylene (PE) inner sheath, which
is filled with jelly to protect it from water ingress. A layer of
water-blocking material is applied around the cable core to prevent
water ingress all the same. After a corrugated steel tape armor is
applied, the cable is completed with a PE outer sheath

Characteristics

· Good mechanical and temperature performance
· High strength looes tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber

· Crush resistance and flexibility
· The following measures are taken to ensure the cable watertight:

- Steel wire used as the central strength member
- Loose tube filling compound

- 100% cable core filling- APL moisture barrier

- PSP enhancing moisture-proof Water-blocking material

Standard

GYTY53 cable complies with Standard YD/T 901-2001as well as IEC 60794

Storage/Operating Temperature

-40℃ to + 70℃

Application

Underground Direct burial

Dimensions of cable constructions

Fiber count	Structure	Fibers per tube	Loose tube diameter (mm)	diameter/pad diameter (mm)	Thickness of Inner jacket (mm)	Thickness of outer jacket (mm)	Cable diameter (mm)	Cable weight (kg/km)
12	1+6	6	1.8 ±0.1	2.2 /2.2	0.9±0.1	1.6±0.1	12.4 ±0.5	138
24	1+6	6	1.8 ±0.1	2.2 /2.2	0.9±0.1	1.6±0.1	12.4 ±0.5	140
48	1+6	12	2.0±0.1	2.3 /2.3	0.9±0.1	1.6±0.1	12.9 ±0.5	152
96	1+8	12	2.0±0.1	2.6/3.5	0.9±0.1	1.6±0.1	14.1 ±0.5	182
144	1+12	12	2.0±0.1	3.0 /6.3	0.9±0.1	1.6±0.1	16.9 ±0.5	256

Packing detail
