Astm A240m Aisi 420 Hot Rolled Stainless Steel Plate 3-20mm Gb/T4237 20cr13

Astm A240 Aisi 420 Stainless Steel Plates AISI 420 Plate for Building

1. Material: AISI 420
2. Standard: ASTM, AISI, JIS, DIN, GB
3.Cold rolled stainless steel plate
Thickness : 0.3mm-3.0mm
Width : 1000mm/1219mm/1500mm
Length : 2000mm/2438mm/4000mm/6000mm or cutting randomly
Model size : 0.3mm-3.0mm(TK)*1000mm(W)*2000mm(L)
0.3mm-3.0mm(TK)*1219mm(W)*2438mm(L)
0.3mm-3.0mm(TK)*1500mm(W)*4000mm(L)

Surface : 2B, BA, 8K, HL, 2D, Golden 8K, Black 8K etc.

4.Hot rolled stainless steel plate
Thickness : 3.0mm-120mm
Width : 1219mm/1500mm/1800mm/2000mm
Length : 2000mm/2438mm/4000mm/6000mm or cutting randomly
Model size : 3.0mm-120mm(TK)*1219mm(W)*2438mm(L)
3.0mm-120mm(TK )*1500mm(W)*6000mm(L)
3.0mm-120mm(TK) *1800mm(W)*6000mm(L)
3.0mm-120mm(TK) *2000mm(W)*6000mm(L)

Surface : No.1/No.4

6.Characteristics and application

Surface finish	Characteristics and application
NO.2B	The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties,No2B could nearly satisfy comprehensive uses.
NO.3	Polished with abrasive belt of git#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc.
NO.4	Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria,but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc.
HL	Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, mainly used as buildings ornaments elevators,door of building, frontal plate etc.
BA	Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror,kitchen apparatus,ornament etc.
8K	The product have excellent brightness and prefer reflexivity can to be the mirror.

7. Payment : Usually 30% of the amount by T/T as deposit , and the balance money shall be paid by T/T after got the faxed B/L.Or L/C at sight .
8. The application field:

a. Automotive:Automotive trim and molding /Exhaustsystem components, tubular manifolds, mufflers/Catalytic converter shells.

b. Construction:Gutters and downspouts, roofing, siding.

c. Kitchenware:Cooking utensils, dishwashers, ovens, range hoods, refrigerators.

d. Chemical processing: Oil refinery equipment, oil burner and heater parts.

e. Appliances:Hot water tanks, residential furnaces, escalator, doors.

f. Power generation:Heat Exchanger tubing.

3Cr12 3mm Stainless Steel Sheets / SS Plate Cold Rolled for Food industry

Quick Detail:

Produce standard: ASTM, AISI, JIS, DIN, GB
Material: 201 202 304 304L 316L 317L 309S 310S 316Ti 321 409L 410 410S
420 420J1 420J2 430 439 444 446 3Cr12 904L S31803 S32205 etc.
Thickness-Cold Rolled: 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 1.0, 1.2, 1.5, 2.0, 3.0, 4.0, 5.0mm

Thickness-Hot Rolled: 3.0, 4.0, 5.0, 6.0, 8.0, 10.0...70mm Or As Required
Width:1000mm, 1219mm, 1500mm, 1800mm, 2000mm

Package: PVC protective film+craft paper+metal pallet or as requirement.
Trade terms: EXW, FOB, CFR, CIF

Description:

Product Item No.: 007sheet-Cosco Steel
Thickness:Cold Rolled: 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 1.0, 1.2, 1.5, 2.0, 3.0, 4.0, 5.0mm
Hot Rolled: 3.0, 4.0, 5.0, 6.0, 8.0, 10.0...70mm Or As Required
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm
Length: 1m-12m Or According to customers request
Material: 201 202 304 304L 316L 317L 309S 310S 316Ti 321 409L 410 410S
420 420J1 420J2 430 439 444 446 3Cr12 904L S31803 S32205 etc.
Technique: Hot/Cold Rolled
Surface finish:2B, 2D, BA, HL(Hair Line), No. 1, No. 3, No. 4, No. 7, Mirror(8K),
Gold mirror, Black mirror etc.
Quality Control: Mill Test Certificate, SGS Or Other Third Party Inspection Also Is Acceptable.
Application: Construction, Machine Building, Container Manufacturing, Shipbuilding, Bridges etc.
Marking: Registered logo,Heat Number,Steel Grade,Standard,Size
Packing: Iron box,wooden pallet,wooden box, or as our customer's requirement
H.S Code: 7219.2200, 7219.2100,7219.3300 etc

3Cr12 ferritic stainless steel is widely used in the field of the South African development of 3 cr12 containing 12%Cr ferriteStainless steel, equivalent to 1.4003 of European brand, is a kind of used to replace coating, weathering steel and carbon steel Aluminum economical ferritic stainless steel.It is simple in processing and manufacturing, the characteristics of the conventional welding technology, welding has been widely used in recent years.Once introduced 3 cr12 in the application of railway freight cars.Now introduce it in the sugar industry, power plant cooling tower, water treatment, civil stockade, utility poles, bus chassis, and other fields of application.

Grade		Chemical Composition
AIST	EN	C	Si	Mn	P	S	Ni	Cr	Others
UNS	EN	max	max	max	max	max	max	Cr	Others
Austenitic stainless steels
201	**	0.15	1	5.5-7.5	0.06	0.03	1	16.00-18.00	N0.25
202	**	0.15	1	7.5-10	0.06	0.03	4.00-6.00	17.00-19.00	N0.25
301	1.431	0.15	1	2	0.045	0.03	6.00-8.00	16.00-18.00	_
301L	1.4318	0.03	1	2	0.045	0.03	6.00-8.00	16.00-18.00	N:0.20
304	1.4301	0.08	1	2	0.045	0.03	8.0-10.50	18.00-20.00	_
304L	1.4307	0.03	1	2	0.045	0.03	9.00-13.00	18.00-20.00	_
316	1.4401	0.08	1	2	0.045	0.03	10.00-14.00	16.00-18.00	Mo:2.00-3.00
316L	1.4404	0.03	1	2	0.045	0.03	10.00-14.00	16.00-18.00	Mo:2.00-3.00
321	1.4541	0.08	1	2	0.045	0.03	9.00-13.00	17.00-19.00	Ti:5*C%
309S	1.4833	0.08	1	2	0.045	0.03	12.00-15.00	22.00-24.00	_
310S	1.4845	0.08	1.5	2	0.045	0.03	19.00-22.00	24.00-26.00	_
Ferritic stainless steels
409L	1.4512	0.03	1	1	0.04	0.03	_	10.50-11.75	Ti:6*C%-0.75
410	1.4006	0.15	1	1	0.04	0.03	_	11.50-13.50	_
410L	1.4003	0.03	1	1	0.04	0.03	_	11.00-13.50	_
439	1.451	0.03	1	1	0.04	0.03	0.5	17.00-19.00	Ti:(0.20+4*(C+N()-1.10,Al:0.15:N:0.030
434	1.4113	0.12	1	1	0.04	0.03	_	16.00-18.00	_
444	1.4521	0.025	1	1	0.04	0.03	_	17.00-20.00	Mo:1.75-2.50 Ti,Nb,Zr:8*(C%+N%)-0.80
430	1.4016	0.12	1	1	0.04	0.03	_	16.00-18.00	_
Martensitic stainless steels
420	1.4021	0.16-0.25	1	1	0.04	0.03	_	12.00-14.00	_
420JS	1.4028	0.26-0.40	1	1	0.04	0.03	_	12.00-14.00	_

Grade		Mechanical Properties
AIST	EN	Yield Strength	Tensile	Elongation	Hardness
UNS	EN	N/mm2	N/mm2	%	HV	HRB
Austenitic stainless steels
201	**	245	640	40	253	100
202	**	245	590	40	218	95
301	1.431	≥205	≥520	≥40	≤218	≤95
301L	1.4318	≥215	≥550	≥45	≤218	≤95
304	1.4301	≥205	≥520	≥40	≤200	≤90
304L	1.4307	≥175	≥480	≥40	≤200	≤90
316	1.4401	≥205	≥520	≥40	≤200	≤90
316L	1.4404	≥175	≥480	≥40	≤200	≤90
321	1.4541	≥205	≥520	≥40	≤200	≤90
309S	1.4833	≥205	≥520	≥40	≤200	≤90
310S	1.4845	≥205	≥520	≥40	≤200	≤90
Ferritic stainless steels
409L	1.4512	≥175	≥360	≥25	≤175	≤80
410	1.4006	≥205	≥440	≥20	≤210	≤93
410L	1.4003	≥195	≥360	≥22	≤200	≤88
439	1.451	≥205	≥415	≥22	≤200	≤89
434	1.4113	≥205	≥450	≥22	≤200	≤88
444	1.4521	≥245	≥410	≥20	≤230	≤96
430	1.4016	≥205	≥420	≥22	≤200	≤88
Martensitic stainless steels
420	1.4021	≥225	≥520	≥18	≥234	≥97
420JS	1.4028	≥225	≥540	≥18	≥247	≥99

Product Tags:


*From:	Your email address is incorrect!
*To:	JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	Stainless Steel Plates
Brand Name:	TISCO,BAO STEEL
Model Number:	420 2cr13
Certification:	ISO,BV
Place of Origin:	China
MOQ:	1 ton
Price:	1800 USD/Ton
Payment Terms:	L/C, T/T
Supply Ability:	2000 tons
Delivery Time:	7 days
Packaging Details:	export packing
Material:	stainless steel
Finishing:	Not Coated
Metal type:	Stainless Steel
Used with:	Flower/Green Plant,Artificial Flower
Size:	Customized Size
Shape:	flat
Usage:	Garden Decoration
Feature:	Firm and durable,durable,Eco-Friendly,Corrosion Resistance,weatherproof
Thickness:	1.5-3 mm or Customized
Surface:	According to customer demand
