Name: 150X150 Mesh Stainless Steel Wire Cloth Plain Weave 005mm 0065mm
Brand: FUHANG
Price: 1 USD

Home > Steel Wire Mesh >

150X150 Mesh Stainless Steel Wire Cloth Plain Weave 0.05mm 0.065mm

Categories	Stainless Steel Wire Cloth
Brand Name:	FUHANG
Model Number:	150X150Mesh
Certification:	ISO9001
Place of Origin:	China
MOQ:	2 Square Meter
Price:	1-30 Square Meter $15/Square Meter >30 Square Meters $13/Square Meter
Payment Terms:	L/C, T/T
Supply Ability:	1200 Rolles Per Month
Delivery Time:	6-8 work days
Packaging Details:	paper tube inside+ wodden box +plastic bag
Name:	150Mesh Plain Woven Stainless Steel Wire Mesh
Material:	304/304L/316/316L
Application:	Filters Woven Wire Mesh
Weave style:	Plain Weave
Type:	Wire Cloth
Technique:	Woven
Wire diameter:	0.05mm , 0.065mm, 0.07mm
Width:	0.3-4meter
Usage:	oil,filter,Printing
Length:	1-30m,30m/roll or as required,30m-100m or customerized
Feature:	corrosion resistent etc.,Anti-corrosion,alkali resist,alkali-resisting etc
Hole shape:	Square Hole
Mesh:	150
Advantage:	Superior wire,standard mesh,factory direct sale,competitive price
Mesh count:	150
Sample:	free
Packing:	paper tube inside+ wodden box

Contact Now

Add to Cart

Company Info.

Anping County Fuhang Wire Mesh Products Co., Limited

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

150X150 Mesh Stainless Steel Wire Cloth Plain Weave 0.05mm 0.065mm

Plain weave wire mesh 150X150mesh cloth stainless steel woven wire mesh screen

Stainless steel wire mesh, also known as wire cloth or wire fabric, is renowned for its remarkable versatility. The distinguishing characteristic of wire mesh is the matrix of wires that are arranged at 90-degree angles. We can produce stainless steel wire mesh with stainless steel wire material in SUS/AISI 201, 202, 304,304L,310, 310S, 316, 316L ,MONEL ,321 ,430 etc.

Plain weave wire mesh 150X150mesh cloth stainless steel woven wire mesh screen with its excellent resistance against acid, alkali, heat and corrosion, find extensively uses in processing of oil, chemical, food, making wire mesh filter, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace and machine making etc.

Features

150 wires per inch
Material can easily bend by hand and cut with scissors or laser
Commonly used for laboratories and filters
This market grade mesh is woven from a standard wire diameter which is heavier than the wire used to weave bolting cloth

Application:
In acid, alkali environment conditions sieving and filtering.
Petroleum industry as mud mesh,.
Chemical fiber industry as screen mesh.
Plating industry as acid cleaning mesh.

Product infomation:

(1) product range : usually,manufactured in 30m ( up to 200) long and in width of 36``, 48``, 1m, 1.2m, 1.5m, 2.0m, 4.0mm etc. or cut to length panels as per client’s requirement.

(2) Packing: water-proof paper , also can be made as per client requirement

(3) weave:This type of mesh is available in Plain Weave, Twill Weave ;

(4) mesh counts: 150 mesh.

(5) sample: available.

Ⅰ. Plain Weave Stainless Steel Wire Mesh Mesh

Mesh Count per Inch	Wire Diameter (mm)	Aperture Size (mm)	Open Area	Weight for Stainless Steel (kg/sq m)
2	1.8	10.9	74%	3.22
2	1.6	11.1	76%	2.54
2	1.4	11.3	79%	1.95
3	2	6.467	58%	5.96
3	1.8	6.667	62%	4.83
3	1.6	6.867	66%	3.82
3	1.4	7.067	70%	2.92
4	2	4.35	47%	7.95
4	1.8	4.55	51%	6.44
4	1.6	4.75	56%	5.09
4	1.4	4.95	61%	3.89
4	1.2	5.1	65%	3.11
4	1	5.35	71%	1.99
4	0.9	5.45	74%	1.61
5	1.2	3.83	57%	3.88
5	1	4.08	65%	2.48
6	1.6	2.633	39%	7.63
6	1.4	2.833	45%	5.84
6	1.2	3.033	51%	4.29
6	1	3.233	58%	2.98
6	0.9	3.333	62%	2.41
6	0.8	3.433	66%	1.91
6	0.71	3.523	69%	1.5
8	1.25	1.925	37%	6.21
8	1.12	2.055	42%	4.99
8	1	2.175	47%	3.97
8	0.9	2.275	51%	3.22
8	0.8	2.375	56%	2.54
8	0.71	2.465	60%	2
8	0.63	2.545	64%	1.58
8	0.56	2.615	68%	1.25
10	0.9	1.64	42%	4.02
10	0.8	1.74	47%	3.18
10	0.71	1.83	52%	2.5
10	0.63	1.91	57%	1.97
10	0.56	1.98	61%	1.56
10	0.5	2.04	65%	1.24
12	0.8	1.317	39%	3.82
12	0.71	1.407	44%	3.01
12	0.63	1.487	49%	2.37
12	0.56	1.557	54%	1.87
12	0.5	1.617	58%	1.49
12	0.45	1.667	62%	1.21
14	0.56	1.254	48%	2.18
14	0.5	1.314	52%	1.74
14	0.45	1.364	57%	1.41
14	0.4	1.414	61%	1.11
14	0.355	1.459	65%	0.88
14	0.315	1.499	68%	0.69
16	0.63	0.958	36%	3.15
16	0.56	1.028	42%	2.49
16	0.5	1.088	47%	1.99
16	0.45	1.138	51%	1.61
16	0.4	1.188	56%	1.27
16	0.355	1.233	60%	1
16	0.315	1.273	64%	0.79
18	0.236	1.175	83%	0.5
20	0.56	0.71	31%	3.12
20	0.5	0.77	37%	2.48
20	0.45	0.82	42%	2.01
20	0.4	0.87	47%	1.59
20	0.355	0.915	52%	1.25
20	0.315	0.955	57%	0.99
24	0.45	0.608	33%	2.41
24	0.355	0.703	44%	1.5
24	0.315	0.743	49%	1.18
28	0.355	0.552	37%	1.75
28	0.315	0.592	43%	1.38
30	0.355	0.492	34%	1.88
30	0.315	0.532	39%	1.48
30	0.28	0.567	45%	1.17
30	0.25	0.597	50%	0.93
30	0.224	0.623	54%	0.75
36	0.25	0.456	42%	1.12
36	0.224	0.482	47%	0.9
36	0.212	0.494	49%	0.8
40	0.224	0.411	42%	1
40	0.212	0.435	47%	0.79
40	0.19	0.445	49%	0.72
40	0.132	0.503	79%	0.35
50	0.21	0.298	34%	1.1
50	0.2	0.308	37%	0.99
50	0.19	0.318	39%	0.9
50	0.16	0.348	47%	0.64
50	0.15	0.358	50%	0.56
60	0.18	0.243	33%	0.97
60	0.16	0.263	39%	0.76
60	0.14	0.283	45%	0.58
70	0.15	0.213	34%	0.78
70	0.14	0.223	38%	0.68
70	0.125	0.238	43%	0.54
80	0.14	0.178	31%	0.78
80	0.125	0.193	37%	0.62
100	0.112	0.142	31%	0.62
100	0.1	0.154	37%	0.5
100	0.09	0.164	42%	0.4
100	0.08	0.174	47%	0.32
120	0.09	0.122	33%	0.48
120	0.08	0.132	39%	0.38
120	0.065	0.147	48%	0.25
140	0.08	0.101	31%	0.45
150	0.071	0.098	34%	0.38
150	0.065	0.109	42%	0.27
165	0.05	0.104	46%	0.2
180	0.06	0.081	33%	0.32
180	0.05	0.091	42%	0.22
200	0.05	0.077	37%	0.25
200	0.04	0.087	47%	0.16
230	0.036	0.074	45%	0.15
250	0.04	0.062	37%	0.2
270	0.04	0.054	33%	0.21
270	0.036	0.058	38%	0.17
300*	0.04	0.045	28%	0.24
300*	0.036	0.055	42%	0.13
325*	0.036	0.042	29%	0.21
325	0.028	0.05	41%	0.13
350*	0.03	0.043	34%	0.16
400*	0.03	0.034	27%	0.18
500*	0.025	0.026	26%	0.16

Ⅱ. Dutch Weave Stainless Steel Wire Mesh

Mesh	Wire Diameter				Weave
	Warp		Shute
	in	mm	in	mm
12x64	0.023	0.58	0.0165	0.42	Plain
14x88	0.019	0.48	0.012	0.30	Plain
14x110	0.016	0.40	0.011	0.28	Plain
24x110	0.014	0.355	0.010	0.25	Plain
16X200	0.014	0.355	0.010	0.25	Twill
30X150	0.009	0.23	0.007	0.18	Plain
20X200	0.0135	0.34	0.011	0.28	Twill
40X200	0.007	0.18	0.0055	0.14	Plain
20X300	0.010	0.25	0.007	0.18	Twill
30X250	0.010	0.25	0.008	0.20	Twill
20X350	0.010	0.25	0.006	0.15	Twill
20X250	0.010	0.25	0.0082	0.21	Twill
50X600	0.007	0.18	0.0035	0.09	Twill
28X400	0.007	0.18	0.005	0.13	Twill
50X250	0.0055	0.14	0.0045	0.11	Plain
28X500	0.007	0.18	0.0045	0.11	Twill
50X700	0.0055	0.14	0.003	0.076	Twill
80X700	0.004	0.10	0.003	0.076	Twill
100X1000	0.004	0.10	0.002	0.051	Twill
165X800	0.0028	0.071	0.002	0.05	Twill
165X1400	0.0028	0.071	0.0016	0.04	Twill
200X1400	0.0028	0.071	0.0016	0.04	Twill
325X2300	0.0014	0.035	0.001	0.025	Twill

FAQ

1. Are you factory/manufacturer or trader?
We are direct factory who owns production lines and workers. Everything is flexible and there is no need to worry about extra charges by the middle man or trader.

2. Which countries do you export to?
Our goods are mainly exported to Australia, Canada, UK, USA, Germany, Thailand,South Korea and so on.

3. Can I get free samples?
If the sample is available, yes, can be free. If unavailable, need to customize.

4. What is your minimum order quantity?
Actually there is no MOQ for our products. But usually we recommend a quantity based on the price which is easy to accept.

5. Which payment method you can accept?
Generally we adopt T/T, LC, Western Union, PayPal, Escrow and Money Gram
