| Categories | OPGW Suspension Clamp |
|---|---|
| Brand Name: | HC , OEM |
| Model Number: | PA-1442 |
| Certification: | CE , SGS , ISO2001 |
| Place of Origin: | CHINA |
| MOQ: | 100PCS |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Sets Per day |
| Delivery Time: | 7 days |
| Packaging Details: | Cartons , Wooden Case , Pallets |
| Length: | 152mm , 188mm |
| Bolt Dia: | 1/2" |
| Weight: | 0.6kgs |
| Width: | 42mm |
| No. Of Parts: | 2 Parts |
| Advantage: | Tightly Wihtout Marring |
We are manufacturingthe lower price straight messenger wire suspension clamp guy wire clamp for overhead line cable .
Straight/Curved suspension clamp for AAC & ACSR Conductor are suitable for connnect suspension insulators into a string and hang the string in tower or connect strain clamp and insulator string in the straight line tower.
Features:
1, The clamp used to secure ,hold the ends of guy strand wires.
2, Parallel grooves trap strand tightly without marring
3, Each bolt has a shoulder to prevent turning while tightening
4, Hot dip galvanzied
| Name | No. of parts | Dimension mm | Bolt Dia. | Cross Weight | Pkg.Qty./carton | |
| straight suspension clamp | 3 | L:152mm | W:42mm | 1/2" | 60kg/100pcs | 40 |
| curved suspension clamp | 3 | L:188mm | W:42mm | 1/2" | 60kg/100pcs | 35 |

|
