| Categories | NMM Large Flow Bead Mill |
|---|---|
| Place of Origin: | China |
| Brand Name: | Boyee |
| Certification: | CE ISO |
| Supply Ability: | 20 Set/Sets per Month that depends on cust need |
| Packaging Details: | Stand export packaging: wooden case, steel frame, PE stretch film |
| MOQ: | 1 - 4 Sets |
| Price: | Negotiable |
| Model Number: | NMM |
| Condition: | New |
| Type: | Sand Mill |
| Product Type: | battery materials, electronics materials, pigments, ink paint |
| Voltage: | 220V/380V |
| Dimension(L*W*H): | 4500*1700*2400mm |
| Warranty: | 1 Years |
| Material: | stainless steel |
| Capacity: | 250 L |
| Motor brand: | ABB |
| Bearing brand: | NSK/SKF |
| Agitator: | Turbine |
| Agitator material: | Ceramic |
| Mechanical seal: | Boyee ODM |
| Grinding media size: | 0.1-0.2mm |
| Explosion-proof: | Yes |
| Application Area: | battery materials, electronics materials, pigments, ink paint |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Power(W): | 120-160 kw |
| Weight: | 5600 kg |
| Port: | Guangzhou China Shenzhen China Hongkong China |
| Company Info. |
| Boyee (Shenzhen) Industrial Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Pharmaceuticals horizontal grinding machine with nano fineness
Product Description
It is widely used to produce battery material,printing inks,ceramic material,microelectronics,semiconductor,cosmetics,
pharmaceuticals,agrochemical,paper making,food,life science,paint,inks,fuel catalyst,lon echange products,metallic oxide,pigments,etc.
Product Features
| Model | Volume (L) | Motor Power (KW) | Medium Size (mm) | Weight (KG) | Dimension(mm) |
| NMM-10 | 10 | 18.5 | 0.3-1 | 1280 | 1800*1200*1550 |
| NMM-30 | 30 | 45 | 0.3-1 | 1850 | 1800*1300*1800 |
| NMM-60 | 58 | 75 | 0.3-1 | 2480 | 3290*1478*1950 |
| NMM-90 | 98 | 75-90 | 0.3-1 | 3050 | 3290*1478*1950 |
| NMM-150 | 120-180 | 160 | 0.3-1 | 5280 | 4500*1700*2400 |


* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
| Packaging | |
| Size | 1100*550*1650 |
| Weight | 80kg |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
|
