TORICH is an enterprise that has been producing precision steel pipes and steel pipe processing for over 20 years, with a factory area of approximately 20000 square meters
| Sign In | Join Free | My benadorassociates.com |
|
| Categories | Seamless Cold Drawn Steel Tube |
|---|---|
| Brand Name: | TORICH |
| Model Number: | ASTM A179 |
| Certification: | CE |
| Place of Origin: | Zhejiang China |
| MOQ: | 3Ton |
| Price: | USD 1000-2000 Per Ton |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 6000 Tons Per Year |
| Delivery Time: | 5-8 Weeks |
| Packaging Details: | In bundles |
| Alloy or not: | Non-alloy |
| Surface treatment: | oiled |
| Standard: | ASTM |
| Application: | Boilers, Superheaters,Heat-exchangers, Condensers |
| O.D.: | 5 - 420 mm |
| Thickness: | 0.5 - 50 mm |
| Length: | <12m or as customer demand |
| Material: | SA179 |
| Company Info. |
| TORICH INTERNATIONAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Standard: ASTM A179, for Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes
Steel grade: SA179
Size: 5-420mm,0.5-50mm, length,max 12000mm
Applications:
for Boilers, Superheaters,
Heat-Exchangers,
High-pressure Boilers,
Steam Boilers
Cold Condensers and High-Pressure Services,
High-Temperature Services for Boiler Constructions
Heat Treatment:
Tubes are heat treated after the final cold draw pass at a
temperature of 1200℉(650℃) or higher
Surface Finish:
Finish Tubes are free of scale.
We have normal heat treatment annealing with black surface.
Have bright annealing with grey and bright surface.
Mechanical Testing:
Flattening Test
Flaring Test
Flange Test
Hardness Test
Chemical Composition
| Material | C | Mn | P | S |
| A179 | 0.06-0.18 | 0.27-0.63 | 0.035max | 0.035max |
Mechanical Property
| Material | Tensile Strength,Mpa | Yield Strength,Mpa | Elongation/% |
| A179 | Min 415 | Min 205 | Max 20 |
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring
Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield
Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking


|
