0.5m Legnth Water Well Screen Pipe SS AISI304 304L 302 316 316L Wedge Wire

SS AISI304, 304L, 302, 316 or 316L Wedge Wire Well Screen Filter Pipe

wedge wire screens, v shaped wire welded stainless steel water well screens, low carbon galvanized water well screen, Johnson screen tube, johnson screen pipe, johnson well screen, johnson wire screen, johnson filter screen, johnson v wire screens,v wire slot tube, wire wrapped screen pipe, oil well screens, dewatering well screen, perfect roundness screen tube, profile wire screen pipe, reverse rolled screen tube, spiral screen tube, screen cylinders, rod based continous slot screens, sand conrol well screen, wire wound screen pipe, stainless steel filter elements, wedge wire roll screen, stainless steel strainer pipe,

Oil & gas well and water well screen of wedge wire structure, fitted with slotted tubes / liners for well screen casing protection and support. Also known as V Slot Well Screen, Water Well Sand Filter or Well Screen Strainer.

Xinlu factory also supplies Stainless Steel couplings, flange and other fittings for the complete SS well screens. The screen is connected by welding or threaded male /female couplings. It can be used in many kinds of medium filtering.

Wedge Wire Well Screen Filter Pipe Application

water well

Juice

Beer
water supply systems
Refining & petrochemical
Filter equipment
Drum Filter
Sand control

Groundwater

Pump Filter

Motor Filter

Dewatering

Pharmaceutical

Groundwater
Architecture & Construction
Food & Beverage Screens
Mineral & Aggregate Processing
OEM Screen Components
Pulp & Paper Screens
Refining & Petrochemical
Waste Water Treatment
Water Well & Oil well
Salt industry

Customer Service: Custom well screens

Inform us of your specifications for the water well screen, including diameter, slot opening size, length and percentage of open area. Based on that information, we can customized your products.

Main specs for Wedge Wire Well Screen Filter Pipe

Well Screen material: stainless steel, galvanized low-carbon steel, or custom materials

Slot opening size: 0.1mm-15mm

Diameter (inches): 2, 3, 4, 5, 6, 8, 10, 12, 14, 16, 20, 29-1000mm

Length: 2.9m, 5.85m. The maximum length is 6.05m

Connection method: beveled, circumferential welded, threaded connection

Wedge Wire Well Screen Filter Pipe Specification

General Technical Information Wedge Wire Well Screen Filter Pipe

Profile wire or wedge wire material:
Width(mm):1.5,1.8,2.3,3.0,3.3,3.7,4.0,4.5
Height(mm): 1.5,2.2,2.5,2.7,3.0,3.6,4.0,4.3,4.5,4.70,5.5

Support rods:
Width(mm): 2.0,2.3,2.5,3.0,3.3,3.7,4.0,4.5.
Height(mm): 1.5,2.2,2.5,2.7,3.0,3.6,4.0,4.5,4.7,5.5.
Round rods : diameter from 2.50mm to 6.0mm. 1.8,2.3,3.0,3.3,3.7,4.0,4.5.
Height(mm): 1.5,2.2,2.5,2.7,3.0,3.6,4.0,4.3,4.5,4.70,5.5.
End Connection: By welding or by threaded male/female coupling.
Slot Size: 0.05,0.08,0.10,0.15,0.20,0.25,0.30,1.0,2.0,5.0... 45mm also achieved upon request.

Product Features: Wedge Wire Well Screen Filter Pipe

1. Continuous opening and high porosity of the SS well screen have greatly increased the water flow area.
2. V-type profile of the structure to avoid clogging and ensure smooth flow.
3. Continuous long-term effective use of the pores.
4. Trapezoidal filter pipe offers a solid structure, high porosity, and accurate poring.
5. Trapezoidal wire filter pipe is easy for washing, long service life, safe, reliable, comprehensive and low cost.

Benefits of Using: Wedge Wire Well Screen Filter Pipe

1. Low cost operation: SS water well screens with high openning area shall favor groundwater infiltration. Abundant water shall reduce the water level’s down, thus to save energy consumption.

2. Reduction of the abrasion of the pump:
Under the same condition, high open area can make the speed of groundwater’s entering into the screen much more slower than any other filtration apparatus, which will avoid sand’s entering into screen because of high pressure, thus reduce the abrasion of the pump.

3. Extend the life span of water wells:
Comparatively, groundwater’s entering into screen with higher open area is much easier than the entering into lower open area metal wire screen.The slow water flow shall extend the life span of the water wells.

4. Reduced consumption of treated water for backwashing
5. Savings in filter height and volume
6. No maintenance, repair or shutdown
7. No need for suspended filter floor

Uses: Stainless steel well screen can be used with the deep well pump for the deep well operation, also used in the water-treating equipments and the environmental protection.

Detail applications listed as below:
1.The sea water transforming into the industrial water and life use water via desalination treatment, running water treatment, water softening treatment.
2. The petroleum industry: Terminal filters and filter screen for the chemical acid, the alkali liquid, the ethyl alcohol and other organic solution recycling filters.

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing , 15-25 working days for mass production.

Q3. Do you have any MOQ limit for the order?

A: Low MOQ, 3pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Airline, sea shipping and rail transportation are all optional.

Or ship by EMS, DHL, UPS, FedEx or TNT, it takes 5-7 days to arrive.

Q5. How to proceed an order?

A: Firstly let us know your need specification or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?

A: Yes. Please inform us formally before our production.

Anping county Xinlu Wire Mesh Products Co.,Ltd is located in Anping county which well knowen of “The hometown of wire mesh in China”.

We are a factory specializing in the production of wedge wire screens with 5 sets wedge wire screen machines and one set laser cutting machine. The diameter production range is from 25.4mm to 2 meters, and the minimum slot can reach 30 microns. various sizes of wedge screen orders can be accepted. All wedge wire screens surface treatment are electrolytically polished or pickled polished or galvanized. Bright, no burrs, no injury to hands. Believe it can meet your needs.
