Description:
The 2.0um Thulium Fiber Lasers are offered with single-mode or multi-mode beam quality optimal for the application, specifically to meet the growing demands of the industrial, medical and R&D markets for high power, compact, efficient, wavelength-selectable CW sources ofthe spectral range of 1900 to 2050nm.Now with higher powers and new options, provide the ideal solution for R&D, medical and industrial market segments.
Features:
Full Fiber Design
Wide Wavelengths Selection
Optimal OEM Solution
| Model | CS-50TLM | CS-60TLM | CS-80TLM | CS-200TLM | CS-500TLM | |
| Optical Parameters | ||||||
| Operation Mode | QCW | CW/Modulation | ||||
| Central Wavelength/nm | 1940±5 | (1980/2013)±5 | (1980/2013)±5 | |||
| Modulation Frequency/Hz | 1-2500Hz | 1-5000Hz | ||||
| Output Average power/W | 50W | 60W | 80W | 200W | 500W | |
| Output Peak Power/W | 500W | 600W | 800W | / | / | |
| Power Range/% | 10-100% | 10-100% | ||||
| Output power Instability(RMS)/% | <±1.5% | <±2.5% | ||||
| Output Fiber connector | SMA905/QBH | QBH | QBH | |||
| Output fiber length/m | 5(Customized) | 5(Customized) | ||||
| Other Parameters | ||||||
| Operating Voltage | 48VDC | 220VAC | ||||
| Cooling | Water/Air cooling | Water cooling | ||||
| Operating Humidity/% | <70 | <50 | <50 | |||
| Operating Temperature/℃ | 10~40 | 10~40 | ||||
| Storage Temperature/℃ | -10~60 | -10~60 | ||||
|
