4x2 New Condition Light Duty Commercial Trucks / Howo Dump Truck CDW 5-10T

4x2 New Condition Light Duty Commercial Trucks / Howo Dump Truck CDW 5-10T

Product Description

CDW 757B3P SERIES
Model	CDW3110A2C3
Cab and Panel	2080 cab,Double torsion bar
Engine	Type: YC4E160-33
	Type:4 cylinder, direct injection, water cooling,4 stroke,Euro III
	Max horse power: 160hp
	Rated revolution: 2600 rpm
	Max. Torque: 520 N.m at 1300~1700 r/min
	Displacement: 4.257 L
	Cylinder bore×route: 110×112 mm
Gearbox	Type: HW90710,Manual with synchro, 10 forward and 2 reverse
Gearbox	Ratio: 11.987,8.973,6.748,4.644,3.805,2.581,1.932,1.453,1,0.819, 9.989(R1),2.151(R2)
Axle	Front type: 145D1A,driven front axle
	Rear axle type: 153N1,Pipa Style,casting axle,with differential
	Rear axle ratio: 6.5
Frame	Frame: 280/10,ladder shaped frame,280mm height,800mmwideth,10mm thickness
	Front overhang: 1061-Ⅱ++,11pcs,telescopic shock absorber
	Rear overhang: 153+,11pcs main spring and 8pcs assistance spring
	Fuel tank:Iron steel,Volume 150L
Steering	Type:Steering wheel
	Steering diameter:450mm
	Max. cycles:5.5
Brake system	Motor brake:Double Circuit air brake
	Parking brake: Brake
	Auxiliary brake: Exhausted Brake
Tyre	Tyre:9.00-20×7
Electronic	Voltage: 24V,cathode ground connection
Dimension	Wheelbase: 3650 mm
	Wheeltrack: 1750 mm/ 1725mm
	Overhang: 1260 mm / 1490 mm
	Approaching angle/Departure angle: 24 / 23
	Inner dimension: 4140mm×2200mm×800mm
	Total dimention: 6395 ×2300×2630mm
Lifting	Single cylinder 180mm×660mm
Weight	Rated mass:4800Kg
	Load capacity:10000 kg
	Total mass:14800 kg
	Front axle load capacity:4590 kg
	Rear axle load capacity:6905 kg

Delivery Detail: Shipped in 30 days after payment

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts
Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
