| Categories | Concrete Mixing Equipment |
|---|---|
| Brand Name: | CIVL |
| Model Number: | CIVL |
| Certification: | ISO,CCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negociable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 set / month |
| Delivery Time: | Within 35 days |
| Packaging Details: | nude |
| Reach height: | 37.4M |
| Reach depth: | 23.7M |
| Theoretical output: | 138/90m3/h |
| Condition: | New |
| Warranty: | 12 months |
| Total weight: | 28150kg |
| made year: | 2021 |
| No. | Item | Unit | Parameter |
|---|---|---|---|
| 1 | Max. speed | km | 90 |
| 2 | Min. turning diameter | m | 18.4 |
| 3 | Brake distance | m | 7 |
| 4 | Approach angle | ° | 31 |
| 5 | Departure angle | ° | 12 |
| 6 | Chassis model | SINOTRUK HOWO | |
| 7 | Total weight | kg | 28150 |
| 8 | 1st axle load | kg | 6780 |
| 9 | 2nd, 3rd axle load | kg | 21220 |
| 10 | Engine model | WD615 | |
| 11 | Max. Engine power | kW | 287 |
| 12 | Max. Engine torque | N.m | 1862 |
| 13 | Max. grade-ability | % | 38 |
| 14 | Fuel consumption limit | L/100km | 34 |
| 15 | Outline dimensions (Length´ Width ´Height) | mm | 11990´2490´3900 |
Technical Data for Pumping Operation
| No. | Item | Unit | Parameter |
|---|---|---|---|
| 1 | Theoretical output | m3/h | 138/90 |
| 2 | Max. delivery pressure | MPa | 8.7/13 |
| 3 | Reach height | m | 37.4 |
| 4 | Reach depth | m | 23.7 |
| 5 | Front outrigger transverse span | mm | 7280 |
| 6 | Rear outrigger transverse span | mm | 6600 |
| 7 | Outrigger longitudinal span | mm | 6860 |
| 8 | Delivery pipe diameter | mm | 125 |
| 9 | Remote control distance | m | 100 |
| 10 | Placing boom slewing range | ° | 370 |



The main products we deal with now are SINOTRUK HOWO, XCMG, SHANTUI, ZOOMLION and SANY. 1.dump trucks; cargo trucks Machine series: 1.Wheel loader,Backhoe loder, brick making machine 2.Roller, 3.Motor Grader, 4.Bulldozer, 5.Excavator, 6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane), 7,forklift and 45t contain reach stacker 8,paver and so on |



|
