| Categories | Heavy Duty Dump Truck |
|---|---|
| Brand Name: | CIVL |
| Model Number: | CIVL |
| Certification: | ISO,CCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000units/month |
| Delivery Time: | Within 35 days |
| Packaging Details: | nude |
| Color: | Option |
| warranty: | Year |
| Lifting: | mid |
| tire: | triangle |
| material: | Q235 |
| Condition: | New |
| Capacity (load): | 21 - 30t |
| Emission standard: | Euro 2 |
Description:
The engine drives the hydraulic pump through the transmission and
power take-off device. The operating system controls the movement
of the piston rod, stopping the compartment at any desired inclined
position. The compartment can be tilted backwards or laterally,
though the former is more common. There are also products
supporting both. The compartment uses it own gravity and hydraulic
control to reset.
The main technical parameter of the tipper is loading weight and
the load volume is also indicated. Load according to the rated
loading capacity. Overloading is strictly prohibited. Trail
operation must be performed for new or overhauled vehicles,
ensuring smooth compartment lifting process without large axial
clearance. Choose proper lubricants by rule for different parts of
the vehicle. Pay attention to the lubrication cycle. The oil for
the lifting mechanism should be replaced on schedule.
Applications:
It is suitable for in normal roads and tough roads, to transport
and unload transport, stone, ore, and others loose materials.
Specifications:
| General information | |||
| Driving Type: | 6X4 | Model No. | ZZ3257N3847A |
| Whole Dimension: | 8545×2496×3370mm | Wheel base: | 3825+1350mm |
| Loading weight: | 20~30 ton | Max speed: | 75km/h |
| Engine | |||
| Engine No: | WD615.47 | Fuel type: | Diesel |
| Max output rate: | 273kw | Horse power: | 371hp |
| Emission standard: | Euro II | Emission: | 9.726L |
| Gearbox | |||
| Gearbox No: | HW19710 | Transmission Type: | Manual |
| Forward: | 10 speed | Reverse: | 2 speed |
| Chassis and tire | |||
| Front axle: | HF9 | Front axle loading: | 9000kg |
| Rear axle: | HC16 | Rear axle loading: | 16000kg |
| Tires | 12.00-20/12.00R20 | Tire quantity: | 11, with spare tire |
| Dump box | |||
| Box dimension: | 5200~5800x2300x1200~1500mm | Hydraulic System: | HYVA front lift |
| Floor thickness | 8mm/10mm/12mm | Side thickness: | 4mm/6mm/8mm |
| Note: Dump box can be customized as customer’s request. | |||
|




Competitive Advantage
1. Humanization easy and convenient to drive,there are many key
close to touch,and it save human labors and also can make the drive
focus on the driving
2. Low oil consumption.Sinotruk adopt the engine that combin the
MAN and technolgoy,it has the perfect oil performance.
3. Load more.with using our truck,it can load more goods in safe.
4. Sufficient stocked spare parts are available for you when you
need to repair your trucks.
Cabin:
|
