New CIVL GR215 Motor Graders In Yellow White 7 tons Operating Weight yellow colour

Categories Motor Graders
Place of Origin: China
Brand Name: CIVL
Certification: ISO,CCC
Model Number: CIVL
MOQ: 1
Price: Negotiable
Packaging Details: Nude
Delivery Time: Within 35 days
Payment Terms: LC/TT etc
Supply Ability: 100 units per week
Certificate: ISO
Color: Yellow|White
Engine model: 4BT3.9
Model: GR215
Operating weight: 7000kg
Product Name: Motor Graders
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

New CIVL GR215 Motor Graders In Yellow White 7 tons Operating Weight yellow colour


SHMC GR215 Motor Graders in Yellow White , 7000kg Operating Weight


Description:
Our main products are:
1. HOWO dump truck, HOWO tractor, HOWO concrete mixer, HOWO parts, water tank, semi-trailers, etc.
2. XCMG truck cranes, XCMG wheel loaders and spare parts.
We markets products in more than 50 countries and districts all over the world, including Russia, Iran, Indonesia, Vietnam, Saudi Arabia, Algeria, Sudan, Angora, Turkey, Brazil, Peru, and Cuba.
We believe that our warm and professional service will bring you pleasant surprises as well as fortune.
Cooperate with us, You can get harmonious service like family.




Specification:

Basic specification

Engine model

4BT3.9

Rated power/speed

75/2400kw/rpm

Dimension(LxWxH)

6880×2375×3150mm

Operating weight(Standard)

7000kg

Performance specification

Travelling speed ,forward

5,10,20,39km/h

Travelling speed ,reverse

8,25km/h

Tractive force(f=0.75)

41.6KN

Max. gradeability

20%

Tire inflation pressure

350KPa

Working hydraulic pressure

16MPa

Transmission pressure

1.3~1.8MPa

Operating specification

Max. steering angle of front wheels

±50°

Max. lean angle of front wheels

17°

Max. oscillation angle of front axle

±15°

Max. oscillation angle of balance box


Frame articulation angle

±27°

Min. turning radius using articulation

5.9m

Biade

Maximum lift above ground

300mm

Maximum depth of cutting

350mm

Maximum blade position angle

45°

Blade cutting angle

28°—70°

Circle reversing rotation

120°

Moldboard width X height

3048×500mm
