| Brand Name: | Huilian |
| Model Number: | V32 86363173 PISTON |
| CertifiCATEEEEEion: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 Pieces |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/A, D/P |
| Supply Ability: | 10000 PCS per month |
| Delivery Time: | 1-7days |
| Packaging Details: | PP Bag Carton |
| Part Name: | Hydraulic Breaker Piston |
| Model: | V32 86363173 |
| Suitable: | 7-26 Ton |
| Material: | Gcr15 9Cr2Mo |
| Type: | Breaker spare part piston |
| Core Components: | Chisel,Diaphragm, Seal Kit,dapmer,wear bush |
| Company Info. |
| Guangzhou Huilian Machine Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
V32 BRV32 Montabert Hydraulic Breaker Spare Parts Piston 86363173 for Excavator Construction Machinery Parts
Spareparts, tools for MONTABERT hydraulic breakers available:
| Acumulator | Complete front head |
| Lower buffer | Nude front head |
| Side Buffer | Stripper |
| Upper buffer | Helicoide |
| Side bolt Washer | Seal kit |
| Thrust ring | Membrane- diaphram |
| Back head | Bushing pin |
| Valve house | Driving piston |
| Cylinder | Strike Piston |
| Housing | Shock absorber |
| Bushing Comby | Retainer tool |
| Lower Bushing | Flanges |
| Seal bushing | Distributor cover |
| Upper bushing | Tie rod with nut |
| Retainer pin | Acumulator bolt |
| Impact disc | Acumulator fixing bolt |
| Distribuitor | Valve |
| Piston | Charging Valve |
| Front head |
Model V32 Quick Reference
| Item | Part Number | Ref# | QTY | Description |
| 1 | 86363173 | 77086 | 1 | Strike piston |
| 2 | 86363165 | 77085 | 1 | Cylinder |
| 3 | 86369725 | 78856 | 1 | Spacer |
| 4 | 86354024 | 73670 | 1 | Shank Stop |
| 5 | 86363140 | 77083 | 1 | Front Guide |
| 6 | 86379336 | 81389 | 1 | Upper chuck bushing |
| 7 | 86373198 | 79766 | 1 | Lower chuck bushing |
| 8 | 86352671 | 73154 | 2 | Rush |
| 9 | 86220639 | 75467 | 2 | Elastic pin |
| 10 | 86352689 | 73155 | 1 | Pin |
| 11 | 86352697 | 73156 | 2 | Lock |
| 12 | 86355773 | 74317 | 1 | Spring |
| 13 | 86378452 | 81151 | 1 | Spring guide |
| 14 | 86378437 | 81149 | 4 | Retaining plug |
| 15 | 86352705 | 73159 | 2 | Retaining pin |
| 16 | 86358504 | 75555 | 1 | Plastic plug |
| 17 | 86231644 | 7294 | 1 | Knee piece axle |
| 18 | 86238466 | 12817 | 2 | Equal lip seal |
| 19 | 86352481 | 73008 | 1 | Tight seal |
| 20 | 86355500 | 74256 | 1 | Knee piece 3/8NPTF |
| 21 | 86352622 | 73140 | 4 | Side rod bolt |
| 22 | 86317435 | 57369 | 4 | Side rod nut Suspension |
| 23 | 86363652 | 77227 | 1 | Support disk |
| 24 | 86388014 | 83592 | 1 | Shock absorber subtle |
| 25 | 86369170 | 78695 | 1 | Support disk |
| 26 | 86388055 | 83599 | 1 | Shock absorber Suspension |
| 27 | 96706163 | 27243 | 6 | Screw H M14 |
| 28 | 86354248 | 73750 | 2 | Suspension |
| 29 | 95842811 | 52383 | 4 | Wear plate bolts |
| 30 | 86307493 | 51743 | 8 | Washer |
| 31 | 86354222 | 73746 | 2 | Wear plate bolts |
| 32 | 86383189 | 53888 | 12 | Fixing cap Screw |
| 33 | 86307493 | 51743 | 48 | Washer |
| 34 | 86255817 | 21834 | 12 | Fixing cap nut |
| 35 | 86420783 | 73859 | 1 | Moil point |
| 36 | 86420791 | 73861 | 1 | Chisel |
| 37 | 86420502 | 93051 | 1 | Seal kit |
| 38 | 86248283 | 17639 | 1 | H.P.Diaphragm |
| 39 | 86265048 | 26428 | 1 | Inflating screw |
| 40 | 86241403 | 14826 | 1 | Inflating ring |
