| Sign In | Join Free | My benadorassociates.com |
|
| Categories | Fiber Optic Cable |
|---|---|
| Model Number: | GYFTY |
| Place of Origin: | China |
| Brand Name: | ODM/OEM |
| Certification: | CE RoHS FCC ISO9001 |
| Packaging Details: | 2 Km to 6 Km/drum , fumigated wooden or iron drum as customer required |
| Supply Ability: | 1000 Kilometer/Kilometers per Day |
| MOQ: | 5000 meters |
| Price: | $0.30/meters 5000-99999 meters |
| Payment Terms: | T/T, Western Union |
| Type: | Outdoor Fiber Optic Cable |
| Number of Conductors: | ≥ 10 |
| Product name: | GYFTY fiber optic cable |
| Application: | Aerial and Duct |
| Jacket Material: | PE |
| Fiber count: | 12 core to 144core |
| Fiber type: | OS1/OS2,OM1,OM2,OM3,OM4 |
| Keywords: | GYFTY |
| Function: | Delivery signal light |
| Length per roll: | 2km/3km/4km 24 core fiber optic cable ADSS |
| heath material: | PE or AT for aerial fiber optic cable ADSS |
| Company Info. |
| A Fiber Solution Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |

Cable type | OD(mm) | NominalWeight(kg/km) | tensile strength(N) | Crush Resistance(N/100MM) | Bending Radius(mm) | ||||||||||
Short-term | Long-term | Short-term | Long-term | Dynamic | Static | ||||||||||
ADSS-2~48Xn | 12.0±0.5 | 140.0 | 3600 | 1200 | 1000 | 500 | 20D | 15D | |||||||
ADSS-96Xn | 14.0±0.5 | 165.0 | 3600 | 1200 | 1000 | 500 | 20D | 15D | |||||||
ADSS-144Xn | 16.0±0.5 | 205.0 | 3600 | 1200 | 1000 | 500 | 20D | 15D | |||||||
Storage/Working temperature(℃) | -40~+70 | ||||||||||||||




|
