High Stability Plywood Turnover Machine , Mold Flipper 180 Degrees

High Stability Plywood Turnover Machine , Mold Flipper 180 Degrees

Plywood Turnover Machine Introduction :

1. The structure of panel turnover machine is made of steel and steel plate by fine welding, ensuring its structural strength and stability;

2. The hydraulic cylinder is of smooth and uniform compaction and easy to control, and the clamping force is adjustable;

3. The plate blank is fed in by means of rolling bearing,which does no damage to the plate blank;

4. The control button and the indicating lamp are all located on the control panel, easy for operation as well nice and practical.

Plywood Turnover Machine process description:

1 First put the product into the turning machine with the driving or forklift, start the operation button, the pressing mechanism automatically presses down (hydraulic) to fix the product, the turning machine starts to turn over, and the pressing mechanism automatically resets (hydraulic) loose after the product completes 180° turning. Open the product, drive or forklift to remove the product; start the reset flip button, flip the machine to reset.
2 materials
The main material is Q235 high quality carbon steel
Shaft material is made of 45# high quality carbon steel

Plywood Turnover Machine Parameters

Plywood Turnover Machine Main features:

1. The double-row chain drive makes the turning part of the turning machine work more smoothly and reliably.
2. Using super worm gear reducer makes the transmission power of the equipment more safe and reliable.
3. The four-wheel mechanism with reasonable structure has a stable bearing.
4. When the 180° is turned over, the double protection switch device (mechanical limit switch and electric limit switch limit) is used to make the turning machine safer.
5. The unique flip surface design ensures that the product fits close to the flipping body, and the turning operation is smooth and safe.
6. Use a jacking or lowering mechanism.
7. Using synchronous mechanical structure to ensure uniformity and stability of the whole machine.
8. Product nature: Pressure does not damage the product itself.

Plywood Turnover Machine Main configuration

Equipment spraying
1) Machine: Egg Green GSB05-1426-2001 (instead of GSB G51001-94)
2) The warning part is yellow
