| Categories | Oilfield Sucker Rods |
|---|---|
| Brand Name: | Zhongshi |
| Model Number: | sucker rod |
| Certification: | API ,ISO ,QHSE |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs |
| Delivery Time: | 2weeks |
| Packaging Details: | exported packing |
| Product name: | Alloy Steel Sucker Rod |
| Grade: | D,KD,HY,K,HL |
| Standard: | API 11B |
| Size: | 3/4",1",5/8"-1-1/8" |
| Length: | 25-30ft |
| Package: | Bundle as per API 11B standard |
| Company Info. |
| Puyang Zhongshi Group Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Advantages
1. The drill rod body is made of high quality geological special
alloy steel pipe, and the drill rod joint is made of high quality
alloy structural steel. After vacuum quenching and tempering
treatment, the fatigue strength and shear strength are largely
improved.
2. Adopting advanced friction welding technology, the drill pipe
has the characteristics of high bending strength and strong
welding.
3. The production equipment completely adopts advanced CNC
processing equipment, high production efficiency, high quality and
stability.
4. It can guarantee the straightness requirements in deep hole
drilling. This product has high fatigue strength and long service
life.
5. According to the actual needs of users, we can design and
produce various special specifications and performance drilling
tools.
Size in (mm) | Rod Body diameter in (mm) | diameter of ext. thread in (mm) | Full size Coupling OD mm (in) | Coupling OD mm (in) | Wrench square W*L mm (in) | Length series m (ft) |
| 5/8 (16) | 5/8 (15.88) | 15/16 (23.81) | 38.10(1.5) | 31.8 (1.25) | 22.2×31.8 (7/8×1-1/4) | 7.62 (25) |
| 3/4 (19) | 3/4 (19.05) | 1-1/16(26.99) | 41.28(1.625) | 38.1 (1.5) | 25.4×31.8 (1×1-1/4) | 9.14 (30) |
| 7/8 (22) | 7/8 (22.23) | 1-3/16 (30.16) | 46.0(1.812) | 41.3 (1.625) | 25.4×31.8 (1×1-1/4) | 0.6 (2), 1 (3) |
| 1 (25) | 1 (25.40) | 1-3/8 (34.93) | 55.6(2.187) | 50.8 (2) | 33.3×38.1(1-5/16×1-1/2) | 2 (6), 3 (10) |
| 1-1/8 (28) | 1-1/8 (28.58) | 1-9/16 (39.7) | 60.33(2.375) | 57.2 (2.25) | 38.1×41.3 (1-1/2×1-5/8) |
Mechanical Properties of Sucker Rods:
| Grade | Min Yield strength 0.2% offset M Pa (psi) | Tensile strength M Pa (psi) | Elongation δ% | Reduction of area ψ% |
| K | 414 (60, 000) | 621-793(90, 000-115, 000) | ≥13 | ≥60 |
| C | 414 (60, 000) | 621-793(90, 000-115, 000) | ≥13 | ≥50 |
| D | 586 (84, 970) | 793-965 (114, 985-139, 925) | ≥10 | ≥50 |
| KD | 590(85, 000) | 793-965 (114, 985-139, 925) | ≥10 | ≥50 |
| HL | 795(115,000) | 965-1,195(140,000-173,339) | ≥10 | ≥45 |
| HY | 540 (78, 300) | 965-1,195(140,000-173,339) | ≥42 | ≥224 |
