32 Inch IR Touch Monitor 1000:1 Contrast Ratio For Outdoor Kiosks

Categories Infrared Touch Monitor
Brand Name: KeeTouch
Model Number: KOT-0320U-IR4P (KOT-320P-010)
Certification: CCC, UL, FCC, CE, CB, RoHS
Place of Origin: Shenzhen,China
MOQ: 1 piece
Price: Negotiable
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 Piece/Pieces per Week
Delivery Time: 7-15 work days
Packaging Details: two pieces per carton
Product name: 32 Inch Infrared Touch Monitor
Display Type: 16:9 Ratio 31.5" TFT-LCD
Suggested Resolution: 1920x1080
Brightness: 280cd/m2
Power Supply: Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz
Weight(N.W/G.W): 13Kg(1pcs)/15Kg(1pcs in one package)
Support System: XP,WIN7,WIN8,WIN10,Linux,Android
Touch input: USB
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

32 Inch IR Touch Monitor 1000:1 Contrast Ratio For Outdoor Kiosks

32 Inch IR Touch Monitor 1000:1 Contrast Ratio for Outdoor Kiosks


Description of IR Touch Monitor:


This 32 inch IR touch monitor is highly durable, which can withstand harsh environments. This IR touch monitor comes with high durability, high accuracy, and multi-touch support. In addition, the IR touch monitor can be compatible with various operating systems and can be easily calibrated for accurate touch input detection. Also, with our professional R&D engineers, customized services can be offered.


Infrared Touch Monitor Specifications



Complete Machine
Model No.KOT-0320U-IR4P (P/N:KOT-320P-010)
SeriesOT
Display Type16:9 Ratio 31.5" TFT-LCD
Active Area698.4*392.85(mm)
Monitor Dimensions (W*H*D)756*453*75.7(mm)
Suggested Resolution1920x1080 @ 60Hz
Support Colors16.7M
Brightness (Typ.)Pure LCD Panel280cd/m2
With Touch Monitor252cd/m2
Response Time (Typ.)8ms
Viewing Angle(Typ.at CR>10))Horizontal(left/right)85°/85°
Vertical(up/down)80°/80°
Contrast Ratio (Typ.)1000:1
Video InputVGADVIHDMI
Frequency (H/V)37.9~80KHz / 60~75Hz
Power Supply

Type: External brick

Display voltage: DC 12V±5%

Input (line) voltage: 100-240 VAC, 50-60 Hz

EnvironmentOperating Temp.0~50°C
Operating RH20%~80%
Storage Temp.-20~60°C
Storage RH10%~90%
MTBF≥30,000 Hours
LED Back Light Life (Typ.)≥30,000 Hours
Weight(N.W/G.W)13Kg(1pcs)/15Kg(1pcs in one package)
Package dimensions851*153*553(mm)(1pcs in one package)
Power ConsumptionStandby Power: ≤2W / Operating Power: ≤40W
Mount Interface

1.VESA 75mm and 100mm

2.Mount bracket, horizontal or vertical mount

OSD ControlButtonsAUTO,+,POWER,-,MENU
FunctionBrightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Agency approvalsCCC, ETL, FCC, CE, CB, RoHS
Regular Warranty1 year
Touch Screen
Touch Type32" Infrared touch screen
Touch inputUSB
Response Time≤32ms
Hardness7H
Light Transmittance≥90%
Support SystemXP,WIN7,WIN8,WIN10,Linux,Android
Active Area702.6*395.8±0.5(mm)
Thickness<5(mm)
Touch Test≥50,000,000 times
Input VoltageDC 5V±5%

Infrared Touch Monitor Mechanical Dimensions



Applications


IR Touch Monitor are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.



Why choose us?


1. Quality products: All our products have passed strict quality inspection by the quality department before shipment.

2. Competitive pricing: With a strong supply chain, our products’ prices are very competitive.

3. Timely delivery: We have raw materials in stock all year round, the goods can be produced and sent out quickly.

4. Responsive Customer Service: Professional after-sales team at any time to provide services to customers.


FAQ:


1. What package do you provide for the IR Touch Monitor?

Our package usually is carton.


2. Do you have stock?

Yes, we have a large quantity of stock for our regular model products.


3. What are the shipping ways?

We will ship the goods according to customer’s requirement. For sample, normally by FedEx, DHL, UPS, TNT. For bulk order, by air or by sea.


4. Do you give any discount for the IR Touch Monitor?

We will do utmost to support you with the competitive price, also good service will be offered.
