Decorative Fabric Wall Panels

Categories Acoustic Room Dividers
Brand Name: EBUNGE
Model Number: Series 65 mm movable partitions
Place of Origin: Guangzhou,China
MOQ: No MOQ
Price: 60-101 USD per square meter
Payment Terms: T/T
Supply Ability: 5000 square meters per month
Delivery Time: Shipped in 10 days after payment, based on the quantity.
Packaging Details: Carton package, MDF batten on four section sides ,foam board on both front face.
Product name: Acoustic Room Dividers
Material: Aluminium frame and mdf board
Height: Less then 4 m
Width: 500-1200 mm
Thickness: 65mm
Function: Space divide,sound proof
Style: Modern style
Warranty: 3-5 years
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Decorative Fabric Wall Panels

Acoustic room dividers decorative fabric wall panels removable partition wall with fabric partition walls for exhibition hall

Specification:

Acoustic partition is made of high-quality anodized aluminum frame with composite materials. The panel has a standard thickness of 65mm and a width up to 1200mm. Maximum height can reach 4500mm tall. Its vertical seal.together with the horizontal top and bottom retractable seals provide excellent acoustic insulation property of maximum STC 53 dB in the laboratory setting. Its high performance per dollar value makes it becomes the most economical suitable for restaurant, schools, office, church, hospitals, shopping arcades, and many other indoor applications products.

Technical parameters:

SeriesBG65BG85BG100
Panel suspensionTop hung onlyTop hung onlyTop hung only
Track systemSingle or twin pointSingle or twin pointSingle or twin point
Panel thickness65mm80mm / 85mm100mm
Panel heightUp to 4000mmUp to 6000mmUp to 18000mm
Max height4000mm6000mm18000mm
Panel width600-1230mm600-1230mm600-1230mm
Frame constructionAluminum frameAluminum frameAluminum frame
Face material9mm9mm / 12mm12mm
Fire safetyOptional Class I or OOptional Class I or OOptional Class I or O
Vertical profilesAluminum anodised with sealing profilesAluminum anodised with sealing profilesAluminum anodised with sealing profiles
Retractable sealsAluminum black with
double rubber seals
Aluminum black with double rubber sealsAluminum black with double rubber seals
Operation of sealsManual, with supplied
operating handle
Manual, with supplied operating handleManual, with supplied operating handle
LockingOptional lock to pass doorsOptional lock to pass doorsOptional lock to pass doors
Pass doorsSingle open in panel or
double open in two panel
Single open in panel or double open in two panelSingle open in panel or double open in two panel
Sound insulation20-32dB Rw28-36dB Rw32-50dB Rw
WeightApprox 22-35kg/sq MApprox 25-40kg/sq MApprox30-48kg/sq M
Finish MaterialPlywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Advantage:

Maximize Your Space.


Acoustic partition walls provide a simple and cost-effective way of generating space. We have installed them in a wide range of commercial and public sector environments including offices, exhibition halls, and conference areas.


Quick to install and easy to operate, acoustic partition walls are popular and functional. They maximize space and versatility in the workplace and provide powerful acoustic and fire performance, whilst seamlessly blending into your interior design thanks to a huge variety of possible finishes.


Packing and shipping

Our normal packing for movable partition wall is carton package, MDF batten on four section sides ,foam board on both front face.

Not full container load,we suggest plywood box packing; full container load,we will packing with plastic film first, then put into a carton box,each partition panel separated loading.
