Double Door Metal Outdoor Telecommunication Cabinet

Factory Price Double Door Waterproof Metal Outdoor telecommunication Cabinet

Technical Data Sheet
Structure
Internal Dimension(H*W*D) :Standard 40U *800*1100mm or any customized size
External Dimension(H*W*D) : Standard 2100*900*1200mm or any customized size
Internal capacity:18U, 22U,24U,27U,30U,32U,35U,37U,40U,42U etc (based on customers requirements)
Ventilated door :With two door, with special lock for outdoor cabinet (support padlock)
Hinge :Embedded
Material: Material left ,right and back part are color steel plate,other parts are Galvanization plate ,insulation thickness
45mm,insulation cotton material is PEF
Material available: Galvanized iron/Aluminum/Stainless steel/Cold-rolled steel etc(based on customers requirements)
Structure : Assembly
Cable enter method :Bottom φ50*5 or customer requirement.
Color :RAL7035/Pantone428C, powder coating finish
Ingress Protection: IP55
Noise Level :60-65dB
Temperature Control Cooling :48vdc high speed
Lighting :LED lamp
48V LED lamps, it will turn on when the door is opened; it will turn off when the door is closed.

- Strong rack inside to be equipped with telecom equipments, power source, battery, temperature control device and other
attachments.
- Digital display the temperature-setting, temperature alarm, temperature parameters inside and outside, and all kinds of other alarm information, etc.
- Cabinet made of low thermal conductivity and fireproof material for heat insulation fireproof.
- Can be installed in any difficult places include the top of mountain and the roof of buildings.
- Wind-proof, sand-proof, rain-proof, sun-proof and anti-theft, protection level IP65.
- Supportcustom-made..

Product Features

Attractive powder coat finish
Galvanised steel base
Anti-theft four-point outdoor cabinet lock, excellent keyhole protection device
IP55 cabinet, walls and roof in double steel with high quality insulation
Anti-theft four-point outdoor cabinet lock, excellent keyhole protection device
High performance Air-conditioning unit for heat removal
Door stopper to hold door open at service
Pass earthquake intensity 8 anti-seismic performance test

Suzhou Langji Technology Co., Ltd. was founded in 2009, it is a high-tech enterprise with R&D, manufacturing and sales department. It is located at the coast of Taihu Lake Suzhou city, the registered capital is 50 million RMB. The whole factory covers 5000 square meters and employs about 200 people with an annual sale of nearly 100 million RMB.

Langji company provides full range of temperature control products and solutions for
- Telecommunication

- Data Center
- Base station

- Solar based installations

- Wireless cell sides & switches
- Industry Automation
- Energy Storage

Suzhou Langji Technology Co., Ltd. is always taking the concept of "well-grounded, ambitious and make all efforts to create national brand of precision air conditioner", holding 3 point management strategy that includes technique, force, and service, tracking the market trend and focusing on the development of products. Based on strong technical force, and advanced design ideas, Langji has promoted many models of precision air condition, heat exchanger, and energy-saving products for base station or equipment room, outdoor communication equipment cabinet and thermostatical battery cabinet etc. to meet the diversified needs of the domestic and overseas customers.

Suzhou Langji Technology Co., Ltd. manages the company and production scientifically according to ISO9001 and ISO14001 international management system. The products are certified by CE and CCC, with stable and reliable quality, Langji products are sold in many countries and regions including China, India, Russia, the Middle East, South-east Asia, South America, Africa, Europe and the USA.
