| Categories | Single FETs, MOSFETs |
|---|---|
| Category: | Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs |
| FET Feature: | - |
| Vgs(th) (Max) @ Id: | 4.5V @ 1.24mA |
| Operating Temperature: | -55°C ~ 150°C (TJ) |
| Package / Case: | TO-220-3 |
| Gate Charge (Qg) (Max) @ Vgs: | 102 nC @ 10 V |
| Rds On (Max) @ Id, Vgs: | 41mOhm @ 24.8A, 10V |
| FET Type: | N-Channel |
| Drive Voltage (Max Rds On, Min Rds On): | 10V |
| Package: | Tube |
| Drain to Source Voltage (Vdss): | 650 V |
| Vgs (Max): | ±20V |
| Product Status: | Active |
| Input Capacitance (Ciss) (Max) @ Vds: | 4975 pF @ 400 V |
| Mounting Type: | Through Hole |
| Series: | CoolMOS™ CFD7 |
| Supplier Device Package: | PG-TO220-3-1 |
| Mfr: | Infineon Technologies |
| Current - Continuous Drain (Id) @ 25°C: | 50A (Tc) |
| Power Dissipation (Max): | 227W (Tc) |
| Technology: | MOSFET (Metal Oxide) |
| Base Product Number: | IPP65R041 |
| Description: | 650V FET COOLMOS TO247 |
