| Categories | Pneumatic Air Cylinders |
|---|---|
| Brand Name: | FESTO |
| Model Number: | DNC-63-50-PPV-A |
| Place of Origin: | China |
| MOQ: | 1pc |
| Price: | EXW USD60-80 |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50 pcs per month |
| Delivery Time: | 7-10working days |
| Packaging Details: | plastic bag, carton，OPP bag |
| Part no: | 163403 |
| Brand: | FESTO |
| Type: | DNC-63-50-PPV-A |
| GTIN: | 4052568134242 |
| Piston diameter: | 63 mm |
| Stroke: | 50 mm |
| Company Info. |
| Airwolf Automation |
| Verified Supplier |
| View Contact Details |
| Product List |
About product
The standards-based cylinder DNC can be ordered either using a fixed part number and order reference or using the modular product system. The type codes listed above represent the standards-based cylinders DNC with fixed part number and order reference only. Variants can only be ordered using the modular product system.
Technical Data
| Stroke | 50 mm |
| Piston diameter | 63 mm |
| Piston rod thread | M16x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 22 mm |
| Basic weight for 0 mm stroke | 1709 g |
| Additional weight per 10 mm stroke | 73 g |
| Type of mounting | Via female thread With accessories |
| Pneumatic connection | G3/8 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium Coated |
| Material seals | TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barre | lWrought aluminium alloy Smooth anodised |
Other size as below
| Type | Order no | Weight(g) | Price |
| DNC-63-20-PPV-A | 1622635 | 1855 | USD60-80 |
| DNC-63-25-PPV-A | 163401 | 1895 | USD60-80 |
| DNC-63-30-PPV-A | 1922636 | 1928 | USD60-80 |
| DNC-63-40-PPV-A | 163402 | 2001 | USD60-80 |
| DNC-63-50-PPV-A | 163403 | 2074 | USD60-80 |
| DNC-63-60-PPV-A | 1922637 | 2147 | USD60-80 |
| DNC-63-70-PPV-A | 1922638 | 2220 | USD60-80 |
| DNC-63-80-PPV-A | 163404 | 2293 | USD60-80 |
| DNC-63-100-PPV-A | 163405 | 2439 | USD60-80 |
| DNC-63-125-PPV-A | 163406 | 2622 | USD60-80 |
| DNC-63-150-PPV-A | 1922639 | 2804 | USD60-80 |
| DNC-63-160-PPV-A | 163407 | 2877 | USD60-80 |
| DNC-63-200-PPV-A | 163408 | 3169 | USD60-80 |
| DNC-63-250-PPV-A | 163409 | 3534 | USD60-80 |
| DNC-63-300-PPV-A | 1922640 | 3899 | USD60-80 |
| DNC-63-320-PPV-A | 163410 | 4045 | USD60-80 |
| DNC-63-400-PPV-A | 163411 | 4629 | USD60-80 |
| DNC-63-500-PPV-A | 163412 | 5359 | USD60-80 |
Attention
1,Before you endorse the parcel, please do open the package, and
check out whether the items are damaged during the shipping
process.
If so, please do refuse to sign for the parcel, the courier will
send back the package to our company. Otherwise we are not
responsible for this...
2,Any order is welcome; we will give discounts and combined
shipping costs for you if you order more or mix order. If you have
any questions,
please feel free to contact us.
There are so many kinds. Hurry to call me!
|
