| Categories | Pneumatic Air Cylinders |
|---|---|
| Brand Name: | FESTO |
| Model Number: | DSBC-63-80-PPVA-N3 |
| Place of Origin: | China |
| MOQ: | 1pc |
| Price: | EXW USD100-120 |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50 pcs per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | plastic bag, carton，OPP bag |
| Part no: | 1383581 |
| Brand: | FESTO |
| Type: | DSBC-63-80-PPVA-N3 |
| GTIN: | 4052568016838 |
| Mode of operation: | Double-acting |
| Weight: | 2236g |
| Company Info. |
| Airwolf Automation |
| Verified Supplier |
| View Contact Details |
| Product List |
About product
1.PPV cushioning: pneumatic cushioning, adjustable at both ends.
2.Wide range of variants provides high level of flexibility.
3.Double-acting.
4.Optionally with protection against rotation.
Technical Data
| Stroke | 80mm |
| Piston diameter | 63 mm |
| Piston rod thread | M16x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 22 mm |
| Basic weight for 0 mm stroke | 1740 g |
| Additional weight per 10 mm stroke | 62 g |
| Type of mounting | Via female thread With accessories Either: |
| Pneumatic connection | G3/8 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium, coated |
| Material piston seal | TPE-U(PU) |
| Material piston | Wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material piston rod wiper | TPE-U(PU) |
| Buffer seal material | TPE-U(PU) |
| Cushioning piston material | POM |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Material nut | Galvanised steel |
| Material bearing | POM |
| Material collar screws | Galvanised steel |
Other size as below
| Type | Order no | Weight(g) | Price |
| DSBC-63-20-PPVA-N3 | 2125490 | 1864 | USD100-120 |
| DSBC-63-25-PPVA-N3 | 1383578 | 1895 | USD100-120 |
| DSBC-63-30-PPVA-N3 | 2125491 | 1926 | USD100-120 |
| DSBC-63-40-PPVA-N3 | 1383579 | 1988 | USD100-120 |
| DSBC-63-50-PPVA-N3 | 1383580 | 2050 | USD100-120 |
| DSBC-63-60-PPVA-N3 | 2125492 | 2112 | USD100-120 |
| DSBC-63-70-PPVA-N3 | 2125493 | 2174 | USD100-120 |
| DSBC-63-80-PPVA-N3 | 1383581 | 2236 | USD100-120 |
| DSBC-63-100-PPVA-N3 | 1383582 | 2360 | USD100-120 |
| DSBC-63-125-PPVA-N3 | 1383583 | 2515 | USD100-120 |
| DSBC-63-150-PPVA-N3 | 2125494 | 2670 | USD100-120 |
| DSBC-63-160-PPVA-N3 | 1383584 | 2732 | USD100-120 |
| DSBC-63-200-PPVA-N3 | 1383585 | 2980 | USD100-120 |
| DSBC-63-250-PPVA-N3 | 1383586 | 3290 | USD100-120 |
| DSBC-63-300-PPVA-N3 | 2125495 | 3600 | USD100-120 |
| DSBC-63-320-PPVA-N3 | 1383587 | 3724 | USD100-120 |
| DSBC-63-400-PPVA-N3 | 1383588 | 4220 | USD100-120 |
| DSBC-63-500-PPVA-N3 | 1383589 | 4840 | USD100-120 |
Max. transverse load Fq as a function of stroke length l
With the Festo Core Range, we have selected the most important products and functions from our broad product catalogue, and added the quickest delivery.
The Core Range off ers you the best value for your automation tasks.
There are so many kinds. Hurry to call me!
|
