| Categories | Pneumatic Air Cylinders |
|---|---|
| Brand Name: | FESTO |
| Model Number: | DFM-40-125-P-A-GF |
| Place of Origin: | China |
| MOQ: | 1pc |
| Price: | EXW USD150-200 |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50 pcs per month |
| Delivery Time: | 7-10working days |
| Packaging Details: | Plastic bag, Carton |
| Type: | DFM-40-125-P-A-GF |
| Part no: | 170868 |
| Brand: | FESTO |
| GTIN: | 4052568139780 |
| Product weight: | 4123 g |
| Material seals: | NBR |
| Company Info. |
| Airwolf Automation |
| Verified Supplier |
| View Contact Details |
| Product List |
About Product
1.Elastic cushioning rings/plates at both ends.
2.Sturdy and precise.
3.The guided drive effortlessly transports and lifts loads of over 200 kg, powerfully and dynamically.
4.Simple operation and long service life.
5.Wide variety and excellent quality.
Technical Data
| Stroke | 125 mm |
| Piston diameter | 40 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Max. speed | 0.8 m/s |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Product weight | 4123 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DFM-40-25-P-A-GF | 170864 | 2217 | USD150-200 |
| DFM-40-50-P-A-GF | 170865 | 2655 | USD150-200 |
| DFM-40-80-P-A-GF | 170866 | 3261 | USD150-200 |
| DFM-40-100-P-A-GF | 170867 | 3595 | USD150-200 |
| DFM-40-125-P-A-GF | 170868 | 4123 | USD150-200 |
| DFM-40-160-P-A-GF | 170869 | 4736 | USD150-200 |
| DFM-40-200-P-A-GF | 170870 | 5437 | USD150-200 |
Attention
1,Before you endorse the parcel, please do open the package, and
check out whether the items are damaged during the shipping
process.
If so, please do refuse to sign for the parcel, the courier will
send back the package to our company. Otherwise we are not
responsible for this...
2,Any order is welcome; we will give discounts and combined
shipping costs for you if you order more or mix order. If you have
any questions,
please feel free to contact us.
Use as a lifting cylinder
A wide range of products with excellent prices. Please hurry to me!
|
