30.5m Flange Type Traditional Galvanized Steel Pole , Electric Power Transmission Poles

Categories Galvanized Steel Pole
Brand Name: milkyway
Model Number: 30.5m Flange Type Philippines
Certification: ISO9001:2015
Place of Origin: Jiangsu
MOQ: one container
Price: USD 130-180/pieces
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 pieces per month
Delivery Time: always 2 weeks
Packaging Details: Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pics will calculation base on the client actually specification and data.
Name: 30.5m Flange Type Philippines Traditional Electric Steel Pole
Design: 30.5m Flange Type Philippines
Height: 100FT
Thickenss: 10mm 12mm 14mm
Design Load: The multidirectional stress
Port: always Shanghai
Galvanization Standard: ASTM A123 average coating thickness 86microns
Safety factor: not less than 1.0
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

30.5m Flange Type Traditional Galvanized Steel Pole , Electric Power Transmission Poles

30.5m Flange Type Philippines Traditional Electric Steel Pole

Description

Part No30.5m Flange Type Philippines Traditional Electric Steel Pole
Height30.5m
Suit forAirport,seaport,plaza,stadium,square,highway,street way
ShapeConoid,multi-pyramidal,columniform,polygonal,conical
Material

Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400,

SS490, to ST52-

Lamp Power20W-400W(HPS/MH) 220V(+-10%)/50HZ
Tolerance of the dimension+-2%
Optical assembly of lighting fixtureIP65

Electroshock resistant

protective grade

Grade I
The casing anti-corrosion performanceClass II

working atmosphone of lighting

fixture

-35 ℃ to +45 ℃
Surface treatment

hot dip galvanzied following ASTM A123,Color polyester power

or any other standard

Joint of polesinsert mode,innerflange mode,face to face joint mode
Design of poleagainst earthquake of 8 grade
Wind speed160 km/hour
Minimum yield strength355 mpa
Minimum ultimate tensile strength490 mpa
Max Ultimate tensile strength620 mpa
StandardISO9001
Length of per sectionwithin 14m once forming without slip joint
Welding

flaw testing,internal and external double welding makes the welding

better

Welding Standard :AWS ( American Welding Society ) D 1.1

Thickness1mm to 15mm
Production Process

Raw material test - cutting - molding or bending - welding(longitudinal) -

dimension - Packages

Packages

Normal cover by mat or straw bale at the top and bottom,anyway also

according to customer request

StyleSize and styles are variable as per customer request


Product Material:


All of our material are purchased from famous mill factory to assure the quality
1. A mill certificate issued by the mill factory with stamp and signature must be provided before unload the material in our factory ,otherwise we have our reason to refuse the material .
2. Before put into production ,all the material must pass the chemical and physical analysis to make sure that they have meet the requested strength and component.
Inspection


To assure our products qualified ,we take steps as follows :


1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management .

2. Introducing ISO management ,We are awared ISO 9001:2008 certificate . .
3. QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment



Company Introduction


Estbilsed in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on
We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on- NEA 220KV 30ft electric lighting poles factory


Best Service: --At Jiangsu Milky Way Steel Poles Co.,Ltd, our #1 priority has always been providing our clients with great quality products and superior Customer service.

Quick Lead Time.--We're dedicated to providing the quickest turnaround times and work Hard to
ensure that all of your deadlines are meet.

Unbeatable Prices-- We continuously strive to find ways of reducing our production costs, and passing the
savings Over to you!

Unbeatable Quality --we always supply good quality also leading products to our VIP customers.

Brand Awareness -- The goal of any strong brand is achieve a level of awareness that instills the
idea of quality and value into all of your customers.

Special Offers. -- In order to maintain our competitive edge, we are constantly running special offers on
our products, consumer goods, and design services. Contact our sales team to see how we can
help you save a lot of money.

Special support.-- we have a policy term to support our VIP customers for products also payment.


Our steel pole, steel poles , steel power poles ,power steel poles, electrical poles, electrical power poles, power poles, power distribution equipment poles , electric power transimission &distribution steel poles ,hot-dip-galvanized steel poles ,lamp poles ,road poles, streeting lighting poles, street lamp poles ,solar street lamps steel poles ,high mast lamp poles,road lamp poles, the steel street lamp poles, hot-dip-galvanized steel lighting ,outdoor lighting ,outdoor lamps ,street lighting poles ,steel post ,street poles, lamp parts ,lighting fixture ,lighting poles ,lighting equipment ,lighting decoration ,lighting product , street lighting body, high mast lighting steel poles &tower,electric poles, round&square street lighting steel poles with double arm or single arm . Stainless steel poles, Flag mast stainless steel pole, aluminum street light poles, traffic lighting steel poles, telecom tower poles , baseplate , bearing plate, base flanges , are made by hot-roll steel coil ,the process as cut plate, bending ,forming,automatic welding,drill holes ,quality check before galvanized, hot dip galvanized or powder coating , final quality check according by client required.
