SUS409L Sheet 2b 2D Finished Suh409L 409L Stainless Steel Sheet

Categories Stainless Steel Sheet
Brand Name: BAOSTEEL TISCO
Model Number: 201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc
Certification: ISO
Place of Origin: China
MOQ: 1 Ton
Price: 1200 -2000 USD/Ton
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20Ton per week
Delivery Time: 5 - 12 days based on the quantity
Packaging Details: standard packing for export
Products: Stainless Steel Sheet
Grade: 200 series 300 series 400 series
Thickness: 0.3 - 3.0mm
Tech: cold rolled
Width: 1000mm 1219mm 1500mm or customs as request
Surface: 2B BA NO.1 NO.4 8K HL Color finishing
Standard: ASTM GB JIS EN DIN
MOQ: 1 Ton
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

SUS409L Sheet 2b 2D Finished Suh409L 409L Stainless Steel Sheet

fSUS409L Sheet 2b 2D Finished Suh409L 409L Stainless Steel Sheet


AISI/SS 409L Sheet is also known as UNS S40900 or EN 1.4512 which is a stable version of grade 409 that is composed of chromium content and some amount of nitrogen and carbon. This type of stainless steel grade is widely used by manufacturers for manufacturing different applications and equipment. Grade 409L is a low-cost option for the corrosion resistant stainless steel. It even has a good combination of corrosion resistance and heat resistance that is an ideal choice for lightly corrosive applications or the environment.

Products409L stainless steel sheet
Thickness0.5 - 12.0mm
StandardJIS, AISI, ASTM, GB, DIN, EN, etc.
Surface2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Width1000mm, 1219mm,etc.
Finish2D
Length2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.

409L SS Sheets Exporter, 409L Stainless Steel CR Sheets, SS 409L HR Sheets, AISI 409L Sheets, Austenitic Stainless Steel 409L Sheet, ASME SA240 Grade 409L Sheets,SS Gr. 409L Sheets


Features of AISI/SS 409L Sheet

  • Corrosion resistance
  • Excellent resistance to the exhaust gas, high temperature, and atmospheric corrosion
  • Good formability and excellent flexibility
  • Low cost
  • Durability

These sheets can easily withstand in high and elevated temperature without getting damaged. However, to prove its quality and durability there are various tests done as per the industrial norms and regulations.

Grade Specifications for Stainless Steel 409L Sheets


GradeWERKSTOFF NR.UNSJIS
SS 409L1.4512S40903SUH 409L

Chemical Properties of SS 409L Sheets

GradeC (max)Si (max)MnCrNiP(max)S (max)Ni(max)Other Elements
SS 409L0.031.001.0010.50-11.701.5 max0.0400.0300.50Ti=6X(C+N)Min., 0.75Max

Mechanical Properties of SS 409L Sheets

ElementTensile Strength %Yield Strength %ElongationHardness (HRB) max
SS 409L3801702088

Testing

  • Radiography test
  • Macro and micro test
  • Third party inspection
  • Flaring test
  • Flattening test
  • PMI test

For all these tests, manufacturers provide approved test certificates. However, when all the tests are done a proper care is given towards the packaging section. These sheets are packed in different quality of packaging material so as to prevent AISI/SS 409L Sheet from damage.
