| Categories | Galvanized Steel Coil |
|---|---|
| Brand Name: | BAOSTEEL WISCO |
| Model Number: | DX51D SGCC |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 2 Ton |
| Price: | 600-860 USD/Ton |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | standard packing for export |
| Products: | galvanized steel coil |
| Thickness: | 0.3 - 3.0mm |
| Width: | 1000mm 1250mm 1500mm or as request |
| Surface: | regular spangle, zero spangle |
| Zinc coating: | Z40 - Z275 |
| Brand: | BAOSTEEL ANSTEEL |
| Service: | cutting |
| Coil ID: | 508mm |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
Oiled Sueface Treatment Zinc Coated Metal with Galvanized Steel Coil Z30-Z275g
Specification of our products
| Products Name | Galvanized Steel Sheet / Galvalume Steel Sheet / Prepainted Galvanized Steel Sheet |
| Thickness | Galvanized steel sheet 0.12 - 3.0mm Thickness |
| Galvalume Steel Sheet 0.25 - 3.0mm Thickness | |
| Prepainted Galvanized Steel Sheet 0.12 - 1.2mm Thickness | |
| Width | 914mm,1000mm,1200mm,1219mm,1220mm,1250mm Or According To Customer's Requirement |
| Length | Custom length as customer requirement |
| Coil Weight | 2Ton - 8 Tons |
| Coil Inner Diameter | 508mm or 610mm |
| Surface | Galvanized steel sheet: Regular spangle / non-spangle Zinc: Z30 - Z275 |
| Galvalume Steel Sheet : AZ40 - AZ180 | |
| Prepainted Galvanized Steel Sheet:Painting Type:PE,HDP,SMP,PVDF | |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, AS ETC |
We are a leading supplier of galvanized steel sheet & coil. Galvanized steel is defined as a carbon steel sheet coated with zinc on both sides. There are two main processes used to produce galvanized steel: continuous hot dipping and electro-galvanizing.
The hot dipping process consists of passing the steel through a bath of molten zinc, while the electro-galvanizing process consists of the application of zinc through electrolytic disposition. The result is a layer of zinc tightly adhering to the base metal through an iron-zinc bonding layer. Our hot dipped galvanized products are manufactured to ASTM A653 specifications; our electro galvanized products conform to ASTM A879 specifications.
A zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.
Product-Coated: Hot Dipped Galvanized | ASTM:A653 | Grade: CS-B | Surface:Min Spangle | Treatment: CT-DryG6028GA (.0217 MAX - .0157 MIN)364860G3030GA (.0187 MAX - .0127 MIN)3648***
| Coating | Thickness | Width | Width | Width |
|---|---|---|---|---|
| G90 | 10GA (.1472 MAX - .1292 MIN) | *** | 48 | 60 |
| 11GA (.1323 MAX - .1143 Min) | *** | 48 | 60 | |
| 12GA (.1174 MAX - .0994 MIN) | *** | 48 | 60 | |
| 13GA (.1014 MAX - .0854 MIN) | *** | 48 | 60 | |
| 14GA (.0865 MAX - .0705 MIN) | 36 | 48 | 60 | |
| 16GA (.0696 MAX - .0575 MIN) | 36 | 48 | 60 | |
| 18GA (.0566 MAX - .0466 MIN) | 36 | 48 | 60 | |
| 20GA (.0506 MAX - .0356 MIN) | 36 | 48 | 60 | |
| 22GA (.0436 MAX - .0296 MIN) | 36 | 48 | 60 | |
| 24GA (.0316 MAX - .0236 MIN) | 36 | 48 | 60 | |
| 26GA (.0247 MAX - .0187 MIN) | 36 | 48 | 60 |
Additionally, the Hot Dipped Galvanized and the Galvannealed products are available in a variety of coating weights including G-90, G-60, G-40, and G-30 for the Hot Dipped Galvanized products, and A-60 and A-40 for the Galvannealed products.
At Curtis Steel, we also offer two different finishes on our 26 & 28 gauge galvanized steel sheet & coils.
|
