Brass Pneumatic System Components Pressure Gauge MA-50-16-1/4 356759 GTIN4052568045777

Categories Pneumatic System Components
Brand Name: FESTO
Model Number: MA-50-16-1/4
Place of Origin: China
MOQ: 1pc
Price: EXW USD10-20
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 pcs per month
Delivery Time: 7-10working days
Packaging Details: Plastic bag, Carton
Type: MA-50-16-1/4
Part no: 356759
Brand: FESTO
Conforms to standard: EN 837-1
Material screw-in stud: Brass
Weight: 70 g
Company Info.
Airwolf Automation
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Brass Pneumatic System Components Pressure Gauge MA-50-16-1/4 356759 GTIN4052568045777

FESTO Pressure gauge MA-50-16-1/4 356759 GTIN4052568045777

About product

1.The different colours make it possible to see at a glance whether the pressure is in the permitted tolerance range.

2.The adjustable red/green range provides additional safety when monitoring compressed air.

3.The coloured red and green segments show when the pressure is in the required pressure range.


Technical Data

Indicating range0 bar ... 16 bar
Indicating range0 psi ... 232 psi
Symbol00991463
Conforms to standardEN 837-1
Nominal size of pressure gauge50
DesignBourdon tube pressure gauge
Type of mountingIn-line installation
Operating mediumInert gases Neutral fluids
Operating pressure0 MPa ... 1.6 MPa
Operating pressure0 bar ... 16 bar
Operating pressure0 psi ... 232 psi
Alternating load factor0.66
Measurement accuracy class2.5
Degree of protectionIP43
Media temperature-20°C-60°C
Ambient temperature-20°C-60°C
LABS (PWIS) conformityVDMA24364-B2-L
Note on materialsRoHS-compliant
Position of connectionCentred, rear side
Pneumatic connectionG1/4
Material in contact with the mediumBrass
Material screw-in studBrass
Material housingABS
Material screenPS
Housing colourBlack
Product weight70 g
Note on operating and pilot mediumNo acetylene No oxygen
ScaleDouble scale Bar (outside scale) psi (inner scale)
