| Categories | Heating And Cooling Heat Pump |
|---|---|
| Brand Name: | SUNRAIN |
| Model Number: | BLN-006TB1 |
| Certification: | TUV |
| Place of Origin: | CHINA |
| Supply Ability: | 5000 Unit/Units per Month |
| Package Size(mm): | 1100X480X1000 |
| EER: | 3.16 |
| Net Weight (kg): | 70 |
| KW Max Input: | 2.7 |
| *Energy class(SCOP) 35℃: | A+++ |
| Max Hot Water Temp.: | 48℃ |
| Company Info. |
| Solareast Heat Pump Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
R32 6KW Floor Mounted 4.68 High COP Air Source Heating And Cooling Heat Pump
Description:
Using DC inverter technology, SUNRAIN products can precisely control the motor speed, ensuring that only the power required to fully match the actual load is used, which is more energy efficient and environmentally friendly than the motors traditionally used for heat pumps, and enables users to reduce energy expenditure.
The precise control of the compressor speed ensures that the water temperature is kept within a much smaller range of the set temperature, allowing the user to remain active in a comfortable environment.At the same time, since the inverter adjusts the rotation frequency of the motor according to the energy demand, a heat pump system with an inverter reaches a comfortable state faster than a heat pump system without an inverter, reducing startup time and reducing noise.
Features:
1. Energe class:A+++
2.Full DC inverter Panasonic compressor and fan motor
3.-30℃ inverter EVI
4. WIFI control
5. R32 refrigerant.
| Model: | BLN-006TB1 | ||
| Power Supply | V/Ph/Hz | 220~240/1/50 | |
| Nominal Heating (Max) (A7/6℃,W30/35℃) | Heating Capacity | kW | 6.46 (2.50-8.30) |
| Power Input | kW | 1.31 | |
| COP | W/W | 4.93 | |
| Nominal Heating (Max) (A7/6℃,W47/55℃) | Heating Capacity | kW | 5.92 |
| Power Input | kW | 1.85 | |
| COP | W/W | 3.21 | |
| Nominal Cooling (Max) (A35/24℃,W12/7℃) | Cooling Capacity | kW | 5.66 |
| Power Input | kW | 1.74 | |
| EER | W/W | 3.25 | |
| ERP Level(Outlet water temp. at 35℃) | / | A+++ | |
| ERP Level(Outlet water temp. at 55℃) | / | A++ | |
| Rated input power | kW | 2.71 | |
| Rated input current | A | 12.00 | |
| Refrigerant / Weight | / | R32 | |
| Rated water flow | m3/h | 1.10 | |
| Fan quantity | / | 1 | |
| Fan motor type | / | DC inverter | |
| Compressor | / | Panasonic / DC inverter / Rotary / EVI | |
| Circulating pump | / | Inverter type / Built-in | |
| IP Class | / | IPX4 | |
| Sound pressure at 1m distance | dB(A) | 50 | |
| Max outlet water temperature | °C | 60 | |
| Water piping connections | / | DN 25 (1") | |
| Pressure drop at rating water flow | kPa | 25 | |
| Operating temperature range (Heating mode) | °C | -30~45 | |
| Operating temperature range (Cooing mode) | °C | 16~45 | |
| Unpacked Dimensions ( L×D×H ) | mm | 1110×445×850 | |
| Packed Dimensions ( L×D×H ) | mm | 1160×530×1010 | |
| UnPacked Weight | kg | 95 | |
| Packed Weight | kg | 105 | |
|
