| Brand Name: | SIEMENS |
| Model Number: | 6EP1935-6ME21 |
| Place of Origin: | CHINA |
| MOQ: | 1PC |
| Price: | EXW USD414-553 |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 100PCS Every month |
| Delivery Time: | 8-15 work days |
| Packaging Details: | carton |
| Brand: | SIEMENS |
| Used in: | KBA 318 |
| GWS Part ID: | 166885427 |
| Net Weight (kg): | 5.546 Kg |
| Packaging Dimension: | 21x 23x 18CM |
| Output: | DC24V / 20A |
| Company Info. |
| Airwolf Automation |
| Verified Supplier |
| View Contact Details |
| Product List |
| describe | |
| SITOP BATTERY MODULE/24V/7AH SITOP battery module 24 V/7 Ah with maintenance free sealed lead batteries for SITOP DC UPS module 6 A, 15 A and 40 A *Ex approval no longer available* | |
| Charging current charging voltage | |
| end-of-charge voltage at DC | |
| ● at -10 °C recommended | 29 V |
| ● at 0 °C recommended | 28.4 V |
| ● at 10 °C recommended | 27.8 V |
| ● at 20 °C recommended | 27.3 V |
| ● at 30 °C recommended | 26.8 V |
| ● at 40 °C recommended | 26.6 V |
| ● at 50 °C recommended | 26.3 V |
| Output | |
| charging current maximum | 1.75 A |
| output voltage at DC rated value | 24 V |
| Safety | |
| design of short-circuit protection | Battery fuse 20 A/32 V (solid-state circuitry blade-type fuse + support) |
| design of the overload protection | Valve control |
| Safety | |
| operating resource protection class | Class III |
| protection class | IP IP00 |
| Approvals | |
| certificate of suitability | |
| ● CE marking | Yes |
| ● UL approval | Yes |
| ● as approval for USA | cURus-Recognized (UL 1778, CSA C22.2 No. 107.1), File E219627 |
| ● cCSAus, Class 1, Division 2 | No |
| ● ATEX | No |
| certificate of suitability | |
| ● EAC approval | Yes |
| ● shipbuilding approval | Yes |
| shipbuilding approval | ABS, DNV GL |
| Marine classification association | |
| ● American Bureau of Shipping Europe Ltd. (ABS) | Yes |
| ● DNV GL | Yes |
| environmental conditions | |
| Operating data note | For storage, mounting and operation of lead-acid batteries, the
relevant DIN/VDE regulations or country-specific regulations (e.g. VDE 0510 Part 2/EN 50272-2) must be observed. You must ensure that the battery site is sufficiently ventilated. Possible sources of ignition must be at least 50 cm away. |
| ambient temperature | |
| ● during operation | -15 ... +50 °C |
| ● during transport -20 ... +50 °C | |
| ● during storage -20 ... +50 °C | |
| relative temporary capacity loss at 20 °C in a month typical | 3% |
| Service life | |
| service life of energy storage | |
| ● typical | capacity falls to 80 % of original capacity (according to EUROBAT) |
| ● at 20 °C typical | 4 a |
| ● at 30 °C typical | 2 a |
| ● at 40 °C typical | 1 a |
| ● at 50 °C typical | 0.5 a |
| ambient temperature during storage | Along with the storage and operating temperature, other factors
such as the duration of the storage period and the charge status during storage have a decisive influence on the possible useful life. Batteries should therefore be stored as briefly as possible, always fully charged, and within the temperature range 0 to +20 °C. |
| Mechanics | |
| type of electrical connection | spring-loaded terminals |
| ● for power supply unit | 1 screw terminal each for 0.08 ... 4 mm² for + BAT and - BAT |
| product component included | Accessories pack with solid-state circuitry fuse 20 A and 30 A |
| width of the enclosure | 186 mm |
| height of the enclosure | 168 mm |
| depth of the enclosure | 121 mm |
| installation width | 206 mm |
| mounting height | 188 mm |
| fastening method | |
| ● wall mounting | Yes |
| ● standard rail mounting | NO |
| ● S7 rail mounting | No |
| fastening method | can be screwed onto flat surface (keyhole mounting for hooking in
to M4 screws) |
| net weight | 6 kg |
| number of cells | 12 |
| battery capacity | 7 A·h |
|
