| Categories | Stainless Steel Strip |
|---|---|
| Brand Name: | TISCO |
| Model Number: | 201 202 301 304 316L 321 310S 410 430 440C |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 2 Ton |
| Price: | 2400 - 3500 USD/Ton |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | standard packing for export |
| Products: | stainless steel strip |
| Thickness: | 0.1 - 10.0mm |
| Width: | within 1500mm |
| MOQ: | 2 Ton |
| Grade: | 200 series 300 series 300 series |
| Surface: | BA 2B NO.4 HL 8K NO.1 |
| Standard: | ASTM EN GB JIS |
| Packing: | wooden frame and water proof paper |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
| Product Name | Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.1mm-6.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L |
| Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
Type 301 is an austenitic chromium-nickel stainless steel that is available in the annealed and cold worked conditions. In the annealed condition, Type 301 offers the highest level of stretch formability of any stainless steel and in the heavily cold worked condition offers the highest strength level of any 300 series stainless steel.
Grade Specification
USA | JP | DE | EUR | CN |
|---|---|---|---|---|
ASTM | JIS | DIN | EN | GB |
301 | SUS301 | X5CrNi 17-7 | 1.4319 | 12Cr17Ni7 |
The typical chemical composition is shown in the table below.
Grade | Standard | 301 Chemical Composition | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
C | Si | Mn | Cr | Ni | P | S | Mo | Others | ||
≤ % | ≤ % | % | % | % | ≤ % | ≤ % | ≤ % | % | ||
301 | ASTM A240 | 0.15 | 1.0 | 2.0 | 16.0 - 18.0 | 6.0 - 8.0 | 0.045 | 0.03 | - | N≤ 0.10 |
1.4319 | EN 10088-2 | 0.15 | 1.0 | 2.0 | 16.0 - 18.0 | 6.0 - 8.0 | 0.045 | 0.03 | - | N≤ 0.11 |
SUS301 | JIS G 4304 | JIS G 4305 | 0.15 | 1.0 | 2.0 | 16.0 - 18.0 | 6.0 - 8.0 | 0.045 | 0.03 | - | N≤ 0.10 |
The mechanical properties are given in the table below.
Grade | Standard | 301 Mechanical Properties | ||||
|---|---|---|---|---|---|---|
Tensile Strength | Yield Strength 0.2% | Elongation >% | Hardness | |||
(MPa) ≥ | (MPa) ≥ | HRB ≤ | HB ≤ | |||
301 | ASTM A240 | 517 | 207 | 40 | 95 | - |
1.4319 | EN 10088-2 | 500 | 205 | 45 | - | 215 |
SUS301 | JIS G 4304 | JIS G 4305 | 520 | 205 | 40 | 95 | 207 |
Properties & Typical Applications
Type 301 is a high strength grade of steel. Its resistance to atmosphere corrosion and its bright, attractive surface make it an excellent choice for decorative structural applications.Applications include automobile molding and trim, wheel cover, conveyor belts, kitchen equipment, roof draining systems, hose clamps, springs, truck and trailer bodies, railway and subway cars.
|
