Name: Powder Metallurgy Gears 12v Mini Dc Gearbox Motor For Electric Lock
Brand: TYHE
Price: 1 USD

Home > Power Transmission >

Powder Metallurgy Gears 12v Mini Dc Gearbox Motor For Electric Lock

Categories	12V DC Gear Motor
Brand Name:	TYHE
Model Number:	TJZ25RB
Certification:	CE/ROHS/ISO9001
Place of Origin:	China
MOQ:	500pcs
Price:	Negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	150000pcs per month
Delivery Time:	15 working days after payment
Packaging Details:	Foam wrapped, carton packed
Size:	φ25mm
Voltage:	1.5v 3v 6v 12v 24v or customized
Speed:	10-1800rpm
Torque:	≤1.5N.m
Gear material:	Powder metallurgy gears
Commutation:	brushes brush
Type:	Gear Motor, DC gear micro Motor
Usage:	Feeding machine, blood pressure meter
Keywords:	Small Size 25mm 3v 6v 9v 12v 24v 05rpm 1nm 5 Watt Mini Dc Geared Box Motor For Actuator Vending Machines Electric Lock

Contact Now

Add to Cart

Company Info.

Wenzhou Tyhe Motor Co., Ltd.

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Powder Metallurgy Gears 12v Mini Dc Gearbox Motor For Electric Lock

Products Description

Small Size 25mm 3v 6v 9v 12v 24v 05rpm 1nm 5 Watt Mini Dc Geared Box Motor For Actuator Vending Machines Electric Lock

2D drawing

Model	End cover dimensions	Motor type	Regular Shaft	Weight
TJZ25RB	φ25mm	RF310	4mm-D cut	80g


Specifications

DC Motor Technical Data
Model	Rated Voltage(V)	No-Load Parameters		Rated Parameters					Stall Parameters
		Speed	Current	Speed	Current	Torque	Output	eff	Torque	Current
		rpm	mA	rpm	A	mN.m	W	%	mN.m	A
310	6	3000	10	2400	0.03	0.46	0.12	62.49	1.38	0.19
310	6	5000	26	4000	0.08	0.72	0.30	62.31	2.16	0.50
310	6	6000	31	4800	0.11	0.79	0.40	62.14	2.37	0.72
310	6	6800	45	5440	0.13	0.84	0.48	61.74	2.52	0.74
DC Motor With Gearbox Technical Data (0.3M)
Gearbox parameters			6V-3000RPM Input				6V-5000RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
19	81	4.8	500.0	0.09	1.79	5.37	833.3	0.24	2.80	8.40
19	81	5.7	421.1	0.09	2.12	6.37	701.8	0.24	3.32	9.97
19	73	10.6	226.4	0.08	3.56	10.68	377.4	0.22	5.57	16.71
19	73	12.5	192.0	0.08	4.20	12.59	320.0	0.22	6.57	19.71
19	73	14.7	163.3	0.08	4.94	14.81	272.1	0.22	7.73	23.18
19	65.6	23.0	104.3	0.08	6.94	20.82	173.9	0.20	10.86	32.59
19	65.6	27.5	87.3	0.08	8.30	24.90	145.5	0.20	12.99	38.97
19	65.6	32.0	75.0	0.08	9.66	28.97	125.0	0.20	15.11	45.34
19	65.6	38.0	63.2	0.08	11.47	34.40	105.3	0.20	17.95	53.84
22	59	51.5	46.6	0.07	13.98	41.93	77.7	0.18	21.88	65.63
22	59	60.5	39.7	0.07	16.42	49.26	66.1	0.18	25.70	77.10
22	59	71.0	33.8	0.07	19.27	57.81	56.3	0.18	30.16	90.48
22	59	83.0	28.9	0.07	22.53	67.58	48.2	0.18	35.26	105.78
22	59	98.0	24.5	0.07	26.60	79.79	40.8	0.18	41.63	124.89
24	53	113.0	21.2	0.06	27.55	82.65	35.4	0.16	43.12	129.36
24	53	133.0	18.0	0.06	32.43	97.28	30.1	0.16	50.75	152.26
24	53	156.0	15.4	0.06	38.03	114.10	25.6	0.16	59.53	178.59
24	53	184.0	13.0	0.06	44.86	134.58	21.7	0.16	70.21	210.64
24	53	215.0	11.2	0.06	52.42	157.25	18.6	0.16	82.04	246.13
24	53	253.0	9.5	0.06	61.68	185.04	15.8	0.16	96.54	289.63
27	47.8	249.0	9.6	0.06	54.75	164.25	16.1	0.14	85.70	257.09
27	47.8	293.0	8.2	0.06	64.42	193.27	13.7	0.14	100.84	302.52
27	47.8	344.0	7.0	0.06	75.64	226.92	11.6	0.14	118.39	355.17
27	47.8	404.0	5.9	0.06	88.83	266.49	9.9	0.14	139.04	417.12
27	47.8	474.0	5.1	0.06	104.22	312.67	8.4	0.14	163.13	489.40
27	47.8	557.0	4.3	0.06	122.47	367.42	7.2	0.14	191.70	575.09
27	47.8	654.0	3.7	0.06	143.80	431.40	6.1	0.14	225.08	675.24
DC Motor With Gearbox Technical Data (0.3M)
Gearbox parameters			6V-6000RPM Input				6V-6800RPM Input
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
Length (mm)	Transmission Efficiency (%)	Gear Ratio	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)	Rated Output Speed (RPM)	Rated Output Power (W)	Rated Torque (mN.m)	Maximum Instantaneous Torque (mN.m)
19	81	4.8	1000.0	0.32	3.07	9.21	1133.3	0.39	3.27	9.80
19	81	5.7	842.1	0.32	3.65	10.94	954.4	0.39	3.88	11.63
19	73	10.6	452.8	0.29	6.11	18.34	513.2	0.35	6.50	19.50
19	73	12.5	384.0	0.29	7.21	21.63	435.2	0.35	7.67	23.00
19	73	14.7	326.5	0.29	8.48	25.43	370.1	0.35	9.01	27.04
19	65.6	23.0	208.7	0.26	11.92	35.76	236.5	0.31	12.67	38.02
19	65.6	27.5	174.5	0.26	14.25	42.75	197.8	0.31	15.15	45.46
19	65.6	32.0	150.0	0.26	16.58	49.75	170.0	0.31	17.63	52.90
19	65.6	38.0	126.3	0.26	19.69	59.08	143.2	0.31	20.94	62.82
22	59	51.5	93.2	0.23	24.00	72.01	105.6	0.28	25.52	76.57
22	59	60.5	79.3	0.23	28.20	84.60	89.9	0.28	29.98	89.95
22	59	71.0	67.6	0.23	33.09	99.28	76.6	0.28	35.19	105.56
22	59	83.0	57.8	0.23	38.69	116.06	65.5	0.28	41.13	123.40
22	59	98.0	49.0	0.23	45.68	137.03	55.5	0.28	48.57	145.71
24	53	113.0	42.5	0.21	47.31	141.94	48.1	0.25	50.31	150.92
24	53	133.0	36.1	0.21	55.69	167.06	40.9	0.25	59.21	177.63
24	53	156.0	30.8	0.21	65.32	195.95	34.9	0.25	69.45	208.35
24	53	184.0	26.1	0.21	77.04	231.12	29.6	0.25	81.92	245.75
24	53	215.0	22.3	0.21	90.02	270.06	25.3	0.25	95.72	287.15
24	53	253.0	19.0	0.21	105.93	317.79	21.5	0.25	112.64	337.91
27	47.8	249.0	19.3	0.19	94.03	282.08	21.8	0.23	99.98	299.94
27	47.8	293.0	16.4	0.19	110.64	331.93	18.6	0.23	117.65	352.94
27	47.8	344.0	14.0	0.19	129.90	389.70	15.8	0.23	138.12	414.37
27	47.8	404.0	11.9	0.19	152.56	457.68	13.5	0.23	162.21	486.64
27	47.8	474.0	10.1	0.19	178.99	536.98	11.5	0.23	190.32	570.96
27	47.8	557.0	8.6	0.19	210.33	631.00	9.8	0.23	223.65	670.94
27	47.8	654.0	7.3	0.19	246.96	740.89	8.3	0.23	262.59	787.78

Please let us know your requirements and we will provide you with transmission solutions.
