| Categories | Energy Storage Lithium Battery |
|---|---|
| Brand Name: | PE |
| Model Number: | PE24100 |
| Place of Origin: | Hunan, China |
| Certification: | CE/RoHS/UN38.3/MSDS |
| Packaging Details: | One Battery One Wooden Case |
| Supply Ability: | 1000 Piece/Pieces per Month |
| MOQ: | 2 pieces |
| Price: | $556.00/pieces 2-9 pieces |
| Battery Size: | 528mm(L)x238mm(W)x218mm(T) |
| Weight: | 24KG |
| The charging ratio: | 1C |
| The discharge rate: | 1C |
| Storage Type: | Normal Storage |
| Anode Material: | LFP |
| Application: | Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Solar Energy Storage Systems, Uninterruptible Power Supplies |
| Capacity: | 100Ah, 2560Wh @C2, 25℃ |
| Nominal Voltage: | 25.6V DC |
| Operating Voltage Range: | 20V DC-28.8V DC |
| BMS: | Smart BMS |
| Cycle Life @ 100% DOD: | >3000 Cycles(100% DOD @C2, 25℃) |
| Cycle Life @ 80% DOD: | >4000 Cycles(80% DOD @C2, 25℃) |
| Cycle Life @ 70% DOD: | >5000 Cycles(70% DOD @C2, 25℃) |
| Dimensions: | 528mm(L)x238mm(W)x218mm(T) |
| Serialization: | 8S1P |
| Battery Box Material: | Cold-rolled Steel Sheet |
| Warranty: | 3years |
| Chargeable: | Yes |
| Port: | Shenzhen |
| Company Info. |
| Hunan Pinsheng Energy Technology Co., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |






Item | Detail |
Battery Type | LiFePO4 |
Capacity | 100Ah, 2560Wh @C2, 25℃ |
Nominal Voltage | 25.6V DC |
Operating Voltage Range | 20V DC-28.8V DC |
BMS | Smart BMS |
Cycle Life @ 100% DOD | >3000 Cycles(100% DOD @C2, 25℃) |
Cycle Life @ 80% DOD | >4000 Cycles(80% DOD @C2, 25℃) |
Cycle Life @ 70% DOD | >5000 Cycles(70% DOD @C2, 25℃) |
Dimensions | 528mm(L)x238mm(W)x218mm(T) |
Serialization | 8S1P |
Battery Box Material | Cold-rolled Steel Sheet |
Weight | 24kg |
Charge Current | 100A Continuous |
Discharge Current | 100A Continous |
Charging Shut-off Voltage | 28.8V |
Discharging Limit Voltage | 20V |
Over-current Protection | 250A, 10s Delay |
Short Circuit Protection | 500A, ≤300 us Delay |
Charging Under/Over Temp Protection | 0℃/55℃ |
Charging under/over Temp Protection | -20℃/60℃ |
Balance Current | ≤200mA |
Self-Discharge Rate | <3% Per Month |





|
