Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

Categories Stainless Steel Sheet
Brand Name: TISCO
Model Number: 316L
Certification: ISO
Place of Origin: China
MOQ: 500 kgs
Price: 1300 - 1480 USD/Ton
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10 Ton per week
Delivery Time: 5 - 12 days based on the quantity
Packaging Details: standard packing for export
Products: Stainless Steel Sheet
Grade: 316L
Standard: ASTM EN JIS GB
Size: 1219*2438mm
Thickness: 0.5 - 3.0mm
Type: cold rolled
Service: cutting, surface treatment
application: auto exhaust pipe
Packing: wooden pallets
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel


Products Specification


Products Name316L Stainless Steel Sheet
StandardASTM EN JIS GB BIS
Thickness

0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm

Surface2B 2D NO.1 or process other surface as request
Standard Size1219*2438mm 1000*2000mm
ServiceSlit Cutting, bending , surface treatment
Other Grade200 Series: 201 202
300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347
400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446
Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy
MOQ500 kgs
PackingWooden Pallets and waterproof paper

Introduce of 316L Stainless Steel

Grade 316L is very similar to 316 stainless steel. It is still considered a molybdenum-bearing grade and has properties that make it highly resistant to corrosive degradation. 316L grade stainless steel differs from 316 in that contain lower levels of carbon. The decreased level of carbon in this stainless steel makes this grade immune from sensitisation or grain boundary carbide precipitation. Because of this unique property, Grade 316L tends to be commonly used in heavy gauge welding situations. Additionally, the lower carbon levels make this grade easier to machine. Like 316 stainless steel, 316L because of its austenitic structure is extremely tough, even in the most extreme of temperatures.


More details of 316L Stainless Steel Sheets


Products316 stainless steel sheet/plate
Width500-2000mm
Length1000-12000mm
ThicknessCold Rolled:0.3-3 mm, Hot Rolled:3-120mm
Materials316
StandardASTM A240 ,ASTM A167,ASTM A176,GB/T3280,JIS4304, EN10088-2,etc
Surface FinishNo.1, No.4, 2B, BA, HL, No.8, Mirror finish, and so on.

Composition Specification (%):

GradeCMnAndPSCrMoInN
316min. max.– 0.082.0– 0.75– 0.045– 0.03018.03.0014.0– 0.10
316Lmin. max.– 0.030

2.0

– 0.75– 0.045– 0.03016.0

18.0

2.00

3.00

10.0

14.0

– 0.10
316Hmin. max.0.10

2.0

– 0.75– 0.045– 0.03016.0

18.0

2.00

3.00

10.0

14.0

Mechanical Property Specification:

GradeTensile Strength (MPa)

min

Yield Strength 0.2% Proof (MPa)

min

Elongation (% in 50mm)

min

Hardness
Rockwell B (HR B)

max

Brinell (HB)

max

3165152054095217
316L4851704095217
316H5152054095217
316H also has a requirement for a grain size of ASTM No 7 or coarser.

DIMENSION FOR STOCK SHEET

No.T*W*L(mm)No.T*W*L(mm)No.T*W*L(mm)
10.3*1000*2000201.5*1219*24383924.0*1500*6000
20.3*1219*2438212.0*1000*20004025.0*1500*6000
30.4*1000*2000222.0*1219*24384130.0*1500*6000
40.4*1219*2438232.5*1000*20004235.0*1500*6000
50.5*1000*2000242.5*1219*24384340.0*1500*6000
60.5*1219*2438253.0*1000*20004445.0*1500*6000
70.6*1000*2000263.0*1219*24384550.0*1500*6000
80.6*1219*2438273.0*1500*60004655.0*1500*6000
90.7*1000*2000284.0*1500*60004760.0*1500*6000
100.7*1219*2438295.0*1500*60004865.0*1500*6000
110.8*1000*2000306.0*1500*60004970.0*1500*6000
120.8*1219*2438318.0*1500*60005075.0*1500*6000
130.9*1000*20003210.0*1500*60005180.0*1500*6000
140.9*1219*24383312.0*1500*60005285.0*1500*6000
151.0*1000*20003414.0*1500*60005390.0*1500*6000
161.0*1219*24383516.0*1500*60005495.0*1500*6000
171.2*1000*20003618.0*1500*600055100.0*1500*6000
181.2*1219*24383720.0*1500*600056105.0*1500*6000
191.5*1000*20003822.0*1500*600057110.0*1500*6000
