| Categories | Stainless Steel Plate |
|---|---|
| Brand Name: | DELTA |
| Model Number: | 316H |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 400 kgs |
| Price: | 4500 -5120 USD/Ton |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10 Ton per week |
| Delivery Time: | 5 - 12 days based on the quantity |
| Packaging Details: | wooden pallets + waterproof paper |
| Products: | stainless steel plates |
| Grade: | 316H |
| Standard size: | 1000*2000mm 1219*2438mm 1500*6000mm |
| Thickness: | 0.6- 30.0mm |
| Brand: | TISCO BAOSTEEL POSCO LISCO |
| Loading Port: | Shanghai Port |
| MOQ: | 200 kgs |
| Packing: | wooden pallets + waterproof paper |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
316H Stainless Steel Plate UNS S31609 Carbon 0.4%-1.0% 316S51 Stainless Steel
More Informations of our Products
| Item | Stainless Steel Plates / Stainless Steel Sheets |
| Main Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Standard | ASTM GB JIS EN DIN BS |
| Thickness | 0.4mm-40mm |
| Stock Thickness | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as request |
| Standard size | 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
| Cold Rolled 316H Stainless Steel Sheets | ||||
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm | 1.0*1219*2438mm |
| 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm | 2.5*1219*2438mm | 3.0*1219*2438mm |
| 0.6*1500*3000mm | 0.8*1500*3000mm | 1.0*1500*3000mm | 1.2*1500*3000mm | 1.5*1500*3000mm |
| 2.0*1500*3000mm | 2.5*1500*3000mm | 3.0*1500*3000mm | ||
| Hot Rolled 316H Stainless Steel Plates | ||||
| 3.0*1500*6000mm | 4.01500*6000mm | 5.01500*6000mm | 6.01500*6000mm | 8.01500*6000mm |
| 10.01500*6000mm | 12.01500*6000mm | 14.01500*6000mm | 16.01500*6000mm | 20.01500*6000mm |
| 24.01500*6000mm | 25.01500*6000mm | 28.01500*6000mm | 30.01500*6000mm | 35.01500*6000mm |
The chemical composition of Type 316H Stainless Steel is provided in the table below.
| UNS NO | Grade | C | Si | Mn | P | S | Cr | Mo | Ni | N |
| S31609 | 316H | 0.04/0.10 | 0.75 | 2.00 | 0.045 | 0.030 | 16.00/18.00 | 2.00/3.00 | 10.00/14.00 | - |
The mechanical properties of Type 316H Stainless Steel are provided in the table below.
| UNS No | Grade | Proof Stress 0.2% (MPa) | Tensile Strength (MPa) | Elongation A5(%) | Hardness Max | |
| HB | HRB | |||||
| S31609 | 316H | 205 | 515 | 40 | 217 | 95 |
The steel lends itself well for use in the petrochemical, gas and chemical industry. Masteel supply Grade 316H to a variety of customers including fabricators of pressure vessels, industrial boilers and heat exchangers.
Benefits of using Grade 316H stainless steel include:
|
