| Categories | Ustc Litz Wire |
|---|---|
| Brand Name: | Rvyuan |
| Model Number: | Copper litz wire |
| Certification: | ISO9001/ISO14001/UL/SGS |
| Place of Origin: | China |
| MOQ: | 10kg |
| Price: | Negotiation |
| Payment Terms: | Negotiation |
| Supply Ability: | Satisfy your demand |
| Delivery Time: | 10 workding days |
| Packaging Details: | Spool with carton |
| Name: | 1USTC155 0.06mm*165 Nylon Served Litz Wire Copper Stranded Wire |
| Diameter: | 0.06mm/38AWG |
| Standard: | GB/T5013.3/IEC60245-3:1994 |
| Conductor: | Copper |
| Insulation: | Enamel |
| Rated Temperature: | 155/180 |
| Key word: | 1USTC155 0.06mm*165 Nylon Served Litz Wire Copper Stranded Wire |
| No. of strands: | 165 |
| Company Info. |
| Tianjin Ruiyuan Electric Material Co,.Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
1USTC155 0.06mm*165 Nylon Served Litz Wire Copper Stranded Wire
The nylon served litz wire is custom-made to meet the customer's specific needs, using a 0.071mm diameter pure copper conductor, consisting of 84 strands, and wrapped with nylon yarn. Available in 155- and 180-degree temperature-resistant options, providing reliability in varying operating conditions. We can use enameled single wire with a minimum thickness of 0.025mm to make silk covered wire.
Item | Single wire diametermm | Conductor diameter mm | O.D.mm | Resistance Ω/m | Dielectric strength V | Pitch(mm) |
Tech requirement | 0.072-0.098 | 0.06 | 1.32 | 0.04222 | 1600 | 26 faults/6m |
± | 0.003 | Max. | Max. | Min. | Max. | |
sample 1 | 0.073 | 0.058 | 1.06 | 0.0378 | 2900 | 8 |
sample 2 | 0.076 | 0.06 | 1.13 | 0.0377 | 3100 | 6 |
|
