AIM Core Component Intelligent Patch Panel Scanner 24 Intelligent
Patch Panels
The AIM Core Component Intelligent Patch Panel Scanner provides
automated management for intelligent building ICT infrastructure,
including structured cabling, network equipment, end equipment, and
users. It serves as the optimal auxiliary management tool for large
local area networks.
Product Application
Through a graphical interactive interface, digital mapping of the
entire ICT infrastructure can be achieved. IT management personnel
and field implementation teams are closely linked through the work
order system. Together with intelligent patch panels, it enables
automated patch cord management for new installations, moves, and
changes across the entire network cabinet infrastructure.
Product Features
- Cortex M4 high-performance CPU processor with powerful edge data
processing capabilities
- Innovative support for both port-type and link-type intelligent
patch panels
- Connects to 24 intelligent patch panels for comprehensive network
coverage
- Automatic detection of illegal intrusion, abnormal disconnections,
and connection anomalies
- Real-time anomaly reporting to AIM system via RJ45 network port
- Built-in firmware supports Chinese and English display interfaces
- Smart cable hunting function for site querying without physical
patch cord manipulation
- Marginal computing capability with periodic smart data reporting
- High reliability design supporting online/offline site display and
real-time port monitoring
- Unique smart diagnosis function for online connection diagnosis
- Automatic re-transmission for transmission delays or anomalies
Application Standards
GB/T 18233 (ISO/IEC 11801); GB 50311; TIA/EIA568-C.2
Specifications
| Dimensions | 280mm * 440mm * 67mm |
| Material | Cold-rolled steel |
| Max. Quantity of Patch Panels | 24 pcs |
| Mode Compatibility | Single/dual configuration |
| Space Utilization | 1U |
| Package List | Manual x1, Scanner x1, Mounting Screws x1 set |
| Unit Weight | 2.5kg |
Support and Services
Our Structured Cabling Accessories product comes with comprehensive
technical support and services to ensure smooth installation and
operation. Our team of experts provides guidance and assistance for
installation, configuration, and maintenance of our products.
We offer training and certification programs to help you become
proficient in using our products and optimizing their performance.
Our support services include online resources such as FAQs, product
documentation, and troubleshooting guides to assist you in
resolving any issues you may encounter.
In addition, we offer warranty and repair services to ensure that
your products are functioning as intended. Our technical support
and services are available to our customers 24/7, ensuring that you
have access to assistance whenever you need it.
Packing and Shipping
Product Packaging
- 1 piece per pack
- Individually wrapped for protection
- Packaged in a durable and compact box
Shipping
- Ships within 7-20 business days
- Ships via standard ground shipping
- Shipping calculated at checkout
Frequently Asked Questions
What is the brand name of this structured cabling accessory?
The brand name of this structured cabling accessory is TC.
What is the model number of this product?
The model number of this product is Dzi-*.
Where is this product manufactured?
This product is manufactured in China.
What is the minimum order quantity for this product?
The minimum order quantity for this product is negotiable.
What are the payment terms accepted for this product?
The payment terms accepted for this product are L/C, T/T, Western
Union, and MoneyGram.
What certifications does this product have?
This product is certified with GB/T 18233 (ISO/IEC 11801); GB
50311; TIA/EIA568-C.2.
What is the packaging detail for this product?
The packaging detail for this product is carton.
Is the price of this product negotiable?
Yes, the price of this product is negotiable.
