| Categories | Rubber Insulated Cable |
|---|---|
| Certification: | ISO9001, CE, CCC |
| Brand Name: | Qifan |
| Model Number: | RVV |
| Place of Origin: | China |
| MOQ: | 100m |
| Price: | usd3-8/meter |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000km/Month |
| Delivery Time: | 30-45days |
| Packaging Details: | wooden drumsPackaging Details Inner Packing: Wooden reel, Plastic reel, and Paper Reel Outer Packing: Carton box, Pull out box, Pallet available Other packing available according to clients' request |
| Model NO.: | RVV |
| Material Shape: | Round Wire |
| Range of Application: | Machine |
| Brand: | QIFAN |
| Transport Package: | Roll Drum |
| Specification: | 10-300 |
| Trademark: | QIFAN |
| Origin: | China |
| HS Code: | 8544492100 |
| Type: | Insulated |
| Conductor Type: | Flexible |
| Application: | Welding Machine |
| Conductor Material: | Flexible Copper |
| Sheath Material: | Rubber |
| Insulation Material: | Rubber |
| Samples: | US$ 0/Piece 1 Piece(Min.Order) | Request Sample |
| Company Info. |
| Fangyu(shanghai)Automation Technology Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Model | Name | Main applications | Working temperature of core ≤0C |
YH | Natural Rubber Sheath for Welding Cable | Always used indoor | 65 |
YHF | Neoprene Rubber Sheath Welding Cable | Always used outdoor | 65 |
Synthetic elastomer Sheath Welding Cable |
Conductor Nominal Section (mm2) | Conductive Core | Thickness of Section Sheath (mm) | Average Outer Diameter (mm2) | 20oC Conductor Resistance≤(Ω/km) | Reference Weight(kg/km) | ||
Number/Diameter of Core(mm) | Min | Max | YH | YHF | |||
10 | 322/0.20 | 1.8 | 7.5 | 9.7 | 1.91 | 146 | 153 |
16 | 513/0.20 | 2.0 | 9.2 | 11.5 | 1.16 | 218 | 230 |
25 | 798/0.20 | 2.0 | 10.5 | 13.0 | 0.758 | 316 | 331 |
35 | 1121/0.20 | 2.0 | 11.5 | 14.5 | 0.536 | 426 | 439 |
50 | 1596/0.20 | 2.2 | 13.5 | 17.0 | 0.379 | 592 | 610 |
70 | 2214/0.20 | 2.4 | 15.0 | 19.5 | 0.268 | 790 | 817 |
95 | 2997/0.20 | 2.6 | 17.0 | 22.0 | 0.198 | 1066 | 1102 |
120 | 1702/0.30 | 2.8 | 19.0 | 24.0 | 0.161 | 1348 | 1392 |
150 | 2135/0.30 | 3.0 | 21.0 | 27.0 | 0.129 | 1678 | 1698 |
185 | 1443/0.40 | 3.2 | 22.0 | 29.0 | 0.106 | 1983 | 2020 |
