| Categories | Solar Energy Lithium Battery |
|---|---|
| Warranty: | 5years |
| Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Su |
| Battery Size: | 4.8KWH |
| Brand Name: | zzlysun |
| Certification: | CE/ROHS/UN38.3/FCC/ |
| Model Number: | LYS48100 |
| Place of Origin: | Henan, China |
| Weight: | 55 |
| Product name: | Lifepo4 Low Voltage Battery |
| Nominal Dis/Charge Voltage: | 43.2~57.6V |
| Communication: | Default:RS485/RS232/CAN Optional:WiFi/4G/Bluetooth |
| Gross Weight: | 55kg |
| Package Size: | 480*650*220mm |
| Relative Humidty: | 65+20%RH |
| Discharge Current: | 50A |
| Cycle: | 3000~6000cycle@DOD 80%/25'C/0.5C |
| Installation: | Stack Installation |
| OEM/ODM: | YES |
| Packaging Details: | Plywood Case |
| Port: | Shanghai/Ningbo/Qingdao/Guangzhou |
| Supply Ability: | 1000 Carton/Cartons per Day |
| MOQ: | 10 kilowatts |
| Price: | $176.00/kilowatts 10-19 kilowatts |
| Company Info. |
| Zhengzhou LingYang New Energy Technology Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |

Model  | LYC48100  | LYC48200  | |||||
Combination  | 15S1P  | 16S1P  | 15S1P  | 16S1P  | |||
Rated Energy  | 4.8kwh  | 5.12kwh  | 9.6kwh  | 10.24kwh  | |||
Usable Energy  | 14.4kwh  | 19.2kwh  | 24kwh  | 28.8  | |||
Standard Discharge current  | 50A  | 50A  | 50A  | 50A  | |||
Max.discharge current  | 100A  | 100A  | 100A  | 100A  | |||
Working Voltage Range(VDC)  | 40.5~54  | 43.2~57.6  | 40.5~54  | 43.2~57.6  | |||
Standard Voltage  | 48VDC  | 51.2VDC  | 48VDC  | 51.2VDC  | |||
Max .Charge Current  | 50A  | 50A  | 100A  | 100A  | |||
Max.charge Voltage  | 54V  | 57.6V  | 54V  | 57.6V  | |||
Cycle  | 3000~6000cycles @DOD 80%/25℃/0.5C  | ||||||
Working humidity  | 65±20%RH  | ||||||
Cooling method  | Natural cooling  | ||||||
Operating Temperature  | -10~+50℃  | ||||||
Installation  | Stack installation  | ||||||
Protection level  | IP20  | ||||||
Max of parallel  | 15PCS  | ||||||
Warranty  | 5·10 years old  | ||||||
Communication  | Defualt:RS485/RS232/CAN Optional:WIFI/4G/Buletooth  | ||||||
Working altitude  | ≤2500m  | ||||||
Certificate  | CE/ROHS/FCC/UN38.3 /MSDS  | ||||||
Product Size  | 400*200*460mm  | 400*240*460mm  | |||||
Package Size  | 460*230*545mm  | 460*270*545mm  | |||||
Net Weight  | 41kg  | 45kg  | 101kg  | 105kg  | |||
Gross Weight(kg)  | 49kg  | 55kg  | 11kg  | 115kg  | |||

















                             |
