| Brand Name: | Longvision |
| Model Number: | LJ Series |
| Certification: | CE, ROHS, UL, FCC |
| Place of Origin: | Guangdong, China |
| MOQ: | 1 square meter |
| Price: | negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 3000 Square Meter/Month |
| Delivery Time: | 7-20 work days |
| Packaging Details: | wooden/carton case |
| Panel Size: | 500*500mm/1000*500mm |
| Pixel Pitch: | P2.6 P2.9 P3.9 P4.8 |
| Installation: | Floor Standing Wall Mounting Hanging |
| Brightness: | 500-1000 nits |
| Module size: | 250X250mm |
| Refresh rate: | 1920-3840Hz |
| Cabinet material: | Die-casting Aluminum |
| Viewing angle: | 160/160 Degree |
| LED type: | SMD 1010 SMD 1212 SMD 1515 SMD 2020 |
| Input voltage: | AC 100-240V 50/60Hz |
Factory Price Cabinet Size High Image Quality Indoor Rental Curved Led Display
* Multiple installation, Hanging and stacking, wall mounting
Specification
Type | Parameter name | p3.91 indoor LED module parameter |
Module constitute | Pixel structure | Table three LED |
LED specification | SMD2121 | |
Pixel composing | 1R1G1B | |
Pixel distance | 3.91mm | |
Module resolution | 64x64dots | |
Moudle size | 250X250mm | |
Pixel density | 65410dots | |
Peak power consumption | 30w | |
Moudle weight | 0.412kg | |
Cabinet parameter | Cabinet type | Die-casting aluminum |
Cabinet dimension | 500X500mm | |
Cabinet resolution | 128X128dots | |
Cabinet area | 0.25m2 | |
Optical parameter | White balance brightness | 1200cd/m2 |
Best visual distance | >3.91m | |
Horizontal viewing angle | 140 | |
Vertical viewing angle | 120 | |
Luminance uniformity | >95% | |
Contrast | 3000:1 | |
Electrical parameter | Maximum power | 479w/m |
Average power | 143W/m | |
Input voltage | AC220V(50HZ) | |
Output voltage | DC5V | |
Processing performance/ Operation parameter | Drive mode | 1/16scan |
Frame frequency | 60Hz | |
Refresh rate | >1920Hz | |
Control method | Synchronous | |
Typcial life values | 100000hrs | |
Working environment temperature | -10~60 | |
Working environment humidity | 10%~70% |
Product Discription



Applicaiton

Q1. What about LED Display MOQ?
|
