| Categories | Telescopic Boom Lift |
|---|---|
| Place of Origin: | Shandong, China |
| Brand Name: | JIUBANG |
| Packaging Details: | Comply with Export Packaging Requirements |
| Supply Ability: | 1000 Unit/Units per Year |
| Price: | discuss in detail |
| Certification: | ISO9001、IAF/CNAS |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Condition: | New |
| Applicable Industries: | Manufacturing Plant, Construction works , Energy & Mining, Other, Advertising Company |
| Showroom Location: | None |
| Lift Mechanism: | Telescoping Lift |
| Lift Drive / Actuation: | Electric Motor |
| Power: | 10Kw |
| Min. Lifting Height: | 330mm |
| Table Size: | 1830 x 760 mm |
| Overall Dimensions: | 8720 x 2490 x 2520 mm |
| Weight: | 9200 kg |
| Warranty: | 1 Year |
| Machinery Test Report: | Provided |
| Video outgoing-inspection: | Provided |
| Marketing Type: | New Product 2020 |
| Warranty of core components: | 1 Year |
| Core Components: | Motor, Pump, Engine |
| Max. speed: | 6.1 Km/h |
| Max. Climb Capability: | 45° |
| Inner turning radius: | 2780 mm |
| Outside turning radius: | 5490 mm |
| Rotary angle of turntable: | 400° discontinuity |
| Swing angle of platform: | ±90° |
| Max. working angle: | 3/5° |
| Max. working wind speed: | 12.5 m/s |
| Port: | Tianjing, Lianyungang, Qingdao, Shanghai port |
| Company Info. |
| Jining Jiubang Construction Machinery Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |


Basic | ||||||
Brand | Jiubang | Drive | electric | |||
Dimensions(L x W x H) | 8720 x 2490 x 2520(mm) | Gross Vehicle Weight | 9200 Kg | |||
Max. speed | 6.1 Km/h | Max. Climb Capability | 45° | |||
Wheelbase | 2520 mm | Swing height of axle | 200 mm | |||
Inner turning radius | 2780 mm | Outside turning radius | 5490 mm | |||
Tyre | 33 x 12/D610 foam filled tyres | |||||
Aerial work platform | ||||||
Working platform dimensions | 1830 x 760 x 1200 mm | Rated load | 250 Kg | |||
Max. working height | 21 m | Max. horizontal height | 19.45 m | |||
Max. horizontal extension | 11.45 m | Max. crossing height | 8.25 m | |||
Working boom | Polygonal Folding arm | Tail pendulum | 0.6 m | |||
Rotary angle of turntable | 400° discontinuity | Swing angle of platform | ±90° | |||
Max. working angle | 3/5° | Max. working wind speed | 12.5 m/s | |||
Mini. ground clearance | 330mm | |||||
Operation mode | Remote / electric | |||||
Power | ||||||
Battery | 8 x 6v/420Ah | Charger | 48v/35A | |||
Drive motor | AC32v/3.3kw | Lifting motor | AC32v/10kw | |||
Auxiliary power | Auxiliary power | |||||
Hydraulic oil tank | 75 L | |||||














|
