60HZ 25kVA 20kW Deutz Diesel Generator Water Cooled 3 Phase Electric Diesel Generator Set

Ⅰ.PRODUCT DESCRIPTION

Water Cooled 60HZ 25kVA 20kW Deutz Diesel Generator Set Electric Diesel Generator

Product Introduce:
Deutz engine diesel generator we have all series from rated 20kva to 750kva.

Application fields:

Diesel generator are used in any situation where a reliable backup power source is necessary to maintain continuity of operations.

Advantage of our Deutz diesel generator :

Deutz diesel generator have a sturdy housing；
Longer lifespan；
Lower maintenance costs；
Lower noise level；
Faster delivery time；
Better team service.

Product parameters:

Specification of 60kVA Deutz Diesel Generator Set

Model		DE-DD30
Max. Power	kVA	28
	kW	22.4
Rate Power	kVA	25
	kW	20
Frequency	Hz	60
Rate Voltage	V	220/127
Rate Current	A	65.6

Specification of Deutz Alternator:

Engine Manufacturer		Deutz (Dalian) Engine Co., Ltd.
Engine Brand		Deutz
Engine Model		BFM3-G1
No. of Cylinder		4 Cylinder in line
Aspiration		Naturally aspirated
Governor		Electric
Engine Max. Output Power	kW	25
Displacement	L	3.2
Starting Voltage	V	12
Bore	mm	98
Stroke	mm	105
Lubrication Oil Capacity	L	7.5

Specification of Control Panel:

Controller Brand	Smartgen
Breaker Brand	Delixi
Breaker Capacity (A)	80
Emergency Stop Button	Supply
Automatic Mains Fail (AMF)	Supply
Fuel Level	Supply
Automatic Transfer Switch	ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

Ⅲ. QUALIFICATION CENTIFICATE:

Ⅳ. FACTORY INTERIOR:

Features:

1. Low water cut out engine protection
2. The Deutz Generator enclosed structure ensures quieter operation
3. Alternator excitation mode brushless self-excitation
4. Four Cylinder, four-stroke, water-cooled diesel engine

If you need Deutz generator with other models technical data, kindly contact us for catalogues!

Fu'an Dellent Electric & Machinery Co., Ltd is located in Fu'an of Fujian province a famous small town  regarded as"The city of China Electrical Machinery."
Established in year 2001, Dellent has grown into a professional manufacturer focuses on design,manufacture, sales, installation and services of diesel generator sets with its power range from 4kVA to 2300kVA.
Dellent DE-series of products have been exported to more than 80 countries including Europe,America, Middle East, Africa, Asia, CIS and other regions. The products are widely used in many fields such as telecommunication system, data center, mining, electric power, highways,engineering companies,financial systems, hotels, railways, armies, airports,commercial buildings, hospitals, factories and etc.That's why Dellent understand customers' needs and wants.
