Z225 1.2mm 1250mm Galvanized Steel Coil GI Sheet Coil For Rolling Shutter Door

Categories Galvanized Steel Coil
Brand Name: Decho
Model Number: Hot dip galvanised steel
Certification: ISO 9001
Place of Origin: China
MOQ: 16 tons
Price: 650~800USD
Payment Terms: L/C, T/T
Supply Ability: 800 tons/ day
Delivery Time: 30~45days
Packaging Details: Horizontal package With Wooden Pallet
Thickness: 1.2mm
Width: 1250 mm
Surface: matt
Coil ID.: 508mm/ 610mm
Coil Weight: 2 tons~16 tons
Packaging: Horizontal package With Wooden Pallet
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Z225 1.2mm 1250mm Galvanized Steel Coil GI Sheet Coil For Rolling Shutter Door

Hot-dip galvanizing is a process of coating steel with a thin zinc layer which used to halt the formation of rust. The surface treatment is done by passing the steel through molten zinc at high temperature.It provides long-term protection for steel products.

The Zinc coating has corrosion resistance and sacrificial corrosion function which delay the production of red rust. The zinc coating of the hot dip galvanized steel is higher than electro-galvanized steel sheet so has better corrosion resistance.

Surface structure of hot dip galvanized steel sheet and coil

Surface structureCode No.FeaturesApplication
Conventional spangleZSpangles condensated on zinc coating
under normal conditions after galvanizing.
Commercial purposes
Small spangleXSurface in spangles smaller than
conventional ones and due to controlled
condensation of zinc coating.
Applications where conventional
spangles cannot meet the surface
appearance requirements.
Skin passed spangleGSurface structure after special skin
pass treatment.
Applications of high surface
quality requirements, such as
color coating base plates.
Skin passed small spangleGX--
Zero spangleNNo visible spangles on coating surface
as a result of a special production process.
-
Zn-Fe alloyRNo spangle, gray, normally matterApplicable to further painting

Surface treatment of hot dip galvanized steel sheet and coil

ItemDescription
Chromate treatment (L)Chromate treatment is a chemical treatment with an aim to prevent white rusts formed on product surfaces during transportation and storage.
Oiling (Y)Oiling is to prevent white rusts formed on product surfaces during transportation and storage.
Chromate treatment+ Oiling (LY)Chromate treatment+ Oiling (LY) This treatment with oiling after surface chromate treatment is to further avoid the forming of white rusts.

JIS G 3302 galvanized steel sheet chemical composition

GradeChemical Composition.% Max
CMnPS
SGHC0.150.80.050.05
SGHC4000.251.70.20.05
SGHC4400.2520.20.05
SGHC4900.320.20.05
SGHC5400.32.50.20.05
SGCC0.150.80.050.05
SGCH0.181.20.080.05
SGCD10.120.60.040.04
SGCD20.10.450.030.03
SGCD30.080.450.030.03
SGCD40.060.450.030.03
SGC3400.251.70.20.05
SGC4000.251.70.20.05
SGC4400.2520.20.05
SGC4900.320.20.05
SGC5700.32.50.20.05

Features Of Galvanized Steel Door

  • Well-sealed, Durable and compact
  • Available in many colors
  • Economical
  • Available in various sizes
